Epson Stylus CX5900 - Manual

The ideal all–in–one solution for the home, home office and small business
Printer
PRINTER TYPE
PRODUCT NAME Epson Stylus CX 5900
PRODUCT CODE C11C657071
PRINTING METHOD On­demand Inkjet (piezoelectric)
NOZZLE CONFIGURATION 90 nozzles each Black, Cyan, Yellow, Magenta
Print Speed
BLACK TEXT (MEMO) A4 (Draft) 27ppm *1
COLOUR TEXT (MEMO) A4 (Draft) 27ppm *2
PHOTO 4" x 6" (10 x 15cm) (Draft) Approx 28 sec) *3+
Print Speed Data Printout Patterns The thumbnail images below show the printout patterns used
to determine print speed specifications.
"Second" rating refers to the time taken to print one page. "ppm" rating refers to the number of
pages printed in one minute. The computer environment we test under is as follows: CPU: 1GHZ
Pentium III; RAM: 128MB; OS: Windows ME; Interface/Connectivity: USB
+ When printed on Epson Premium Glossy Photo Paper
RESOLUTION
5760 x 1440 optimised dpi with 3pl
droplets 5760 Optimised dpi using Resolution Performance
Management (RPM) Technology
PRODUCT DIMENSIONS
­ 463mm (W) x 354mm (D) x 181mm (H)
WEIGHT 6.7kg
PAPER HANDLING
PAPER SIZES A4, letter, legal, 13x18cm, 10x15cm, 9x13cm, 13x20cm,
20x25cm, A6, A5, B5, Envelope: C6(162 x 114mm), No 10
(241.3 x 104.8mm), DL (220 x 110mm)
PAPER INPUT CAPACITY 100 sheets, A4 Plain Paper (60gsm)
* True BorderFree™ printing is available for the following media sizes: 4" x 6", 5" x 7" and A4. Media
types recommended : Premium Glossy Photo paper A4, 4" x 6" and 5" x 7", Matte Paper ­
Heavyweight. BorderFree prints are media dependent.
Scanner
SCANNER TYPE A4 Flatbed colour image CIS with CCD sensor
DOCUMENT SIZE A4 or Letter
PIXEL DEPTH Input 48bits (16bits/colour) / output 24bits (8bits/colour)
SCANNING RESOLUTION 1200 x 2400 dpi
SCANNING SPEED @600dpi: Colour 15 msec/lineMonochrome: 5 msec/line
@300dpi:Colour: 10 msec/lineMonochrome: 3 msec/line
Copy Function
COPY SPEED
Black text memo (A4) Approx 27 cpm (Draft)
Colour text memo (A4) Approx 27 cpm (Draft)
STANDALONE COPY FUNCTIONALITY
COPY MODES: Standard copy mode
Small margin copy mode
BorderFree copy mode (Glossy Photo Paper 4"x6")
Repeat copy mode
General
OPERATING SYSTEMS
PRINTER DRIVERS * Mac® OS 10.2.8 or later, Microsoft® Windows® 98SE / 2000 /
ME / XP / XP 64­bit
* Drivers if available are downloadable from Tech Epson
COMPATIBLE MEMORY CARDS
xD­Picture Card, xD­Picture card type M, xD­Picture Card Type H,
CompactFlash, MicroDrive, Memory Stick, Memory Stick Duo )with
adaptor), MagicGate Memory Stick, MagicGate Memory Stick Duo,
Memory Stick PRO, Memory Stick PRO Duo (with adaptor), SD Card,
SDHC, MiniSD (with adaptor), MiniSDHC (with adaptor), MultiMediaCard,
MicroSDHC (with adaptor)
ONTROL PANEL 2" Epson Photo Fine™ Colour LCD Screen
ELECTRICAL SPECIFICATIONS
RATED VOLTAGE AC 220 ~ 240V
RATED FREQUENCY 50 ~ 60Hz
POWER CONSUMPTION Approx. 13W Standalone copying (ISO10561 Letter Pattern)
INTERFACES
USB 2.0 (Hi­Speed) Type­B Interface for PC and Mac connections
PRINTER SOFTWARE (AVAILABLE ON CD­ROM ONLY)
SOFTWARE TOOLS* Epson Creativity Suite 1.1
Epson File Manager
Epson Scan Assist
Epson Attach to Email
Epson Copy Utility
Epson Easy Photo Print
Epson Web­To­Page
PIF designer/PIF installer
Online Guide
WARRANTY
­
12 months return to
base
Standard
­ Optional Additional 2 Year Warranty 3YWCX590 0 (*Australia only)
LIGHTFASTNESS #
LIGHTFASTNESS # 120 years on Epson Matte Paper ­ Heavyweight
LIGHTFASTNESS TEST CRITERIA (INDOOR DISPLAY CONDITIONS)
Light source Fluorescent light
Intensity 70k lux
Temperature 24°C
Humidity 60% RH
Glass Mount 2mm, soda lime
Fade Criteria Pure YMC 30% loss at OD=1
Dispaly Life Calculation Total illuminance/(500 lux x 10 hours x 365 days = 1 year)
# Data is calculated using accelerated simulation of fading under indoor preservation conditions
including fluorescent light indoor display. Temperature, humidity and some atmospheric gases may
also affect the rate of fading. The estimated lightfastness period does not indicate the colour
changing or the durability of the paper itself. Epson recommends that your prints be stored in a
photo album (or plastic photo storage box) in acid free, archival sleeves commonly available from
most camera shops.
Tests developed and conducted by Epson under fluorescent light (indoor display condition) with
glass mount. The data is calculated by Epson's accelerated test of prints on specialty media.
INK CARTRIDGES
BLACK INK
Black (T0731)
COLOUR INK
Cyan (T0732), Magenta (T0733), Yellow (T0734),
The Epson Intellidge™ Ink System is designed to work perfectly in harmony with the printer and
your choice of media to ensure you get:
l the very best of print quality every print, every time
l and trouble­free, peace­of­mind printing every print, every time
The Epson Intellidge™ Ink System brings maximum benefits, maximum ink usage and the
interchange of Epson cartridges suitable for this model.
The Epson Intellidge™ Ink System gives you easy­to­see, always available information about all
your ink levels.
This printer is designed to be used only with Genuine Epson
Intellidge™ ink cartridges
Intellidge™ Ink cartridges are not designed for refill.
It's now easier for you to identify Genuine Epson cartridges.
Epson is gradually replacing the current hologram with the new
anti­counterfeit Color Shifting Label.
As an International ENERGY STAR Partner, Epson has determined that this product meets the
International ENERGY STAR guidelines for energy efficiency. Epson is the registered trademark of
Seiko Epson Corporation. Epson trademarks of Seiko Epson Corporation. All other names and
company names used herein are for identification purpose only and may be the trademarks or
registered trademarks of their respective owners. Epson disclaims any and all rights in those marks.
All print samples shown herein are simulations. Specifications are subject to change without notice.
