WARNING

Do not perform maintenance or assembly procedures with engine

running.

C

E

D

6. Rotate locator pin (A) 1/4 turn clockwise to engage lower shaft

hole. Insure locator pin is fully engaged by gently twisting

lower drive shaft. Locator pin (A) should snap flush in coupler.

Full engagement will prevent further shaft rotation.

7. Secure lower shaft assembly to coupler by tightening clamping

knob (D).

NOTE

Earlier model Power Heads may have shorter couplings. Short

couplings fit flush to decal point (E). New couplings are 4-3/4 in.

long, and fit flush to line (C).

NOTE

Lower bearing housing and head assembly must be in line with the

engine.

A

power

head

shafT

/

aTTaChmenT

lower

shafT

assembly

Parts Required: PAS or SRM-SB Power Head w/Shaft & Coupling.

1. Set Power Head/Shaft Assembly on a level surface.

2. Pull locator pin (A) and rotate counter clockwise 1/4 turn to lock

out position.

3. Remove vinyl cap from attachment drive shaft.

4. Remove cardboard spacer, if necessary.

5. Carefully fit attachment lower drive shaft assembly into coupler (B)

to decal assembly line (C), making sure that the inner lower drive

shaft engages into the upper drive shaft mount.

A

B

D
