PAS R

APid

L

oAdeR

TM

C

uRved

S

hAfT

T

RiMMeR

A

TTAChMenT

o

PeRAToR

'

S

M

AnuAL

11

lubrICaTIon

Level 1.

Parts Required: POWER BLENDX

TM

8 oz. (P/N 91014) or

Lithium Base Grease.

1. Remove plastic shield.

2. Loosen bearing housing locating screw (A), at the top of the hous-

ing, loosen mounting screw (B) and remove gear case from drive

housing.

3. Pull the flexible drive shaft (C) from the drive housing, wipe clean

and recoat with a thin coating [1/2 oz. (15 ml)] of grease.

4. Slide the flexible drive shaft back in the drive housing being care-

ful not to get dirt on the flexible drive shaft.

5. Install the bearing housing and shield.

A

B

nylon

lIne

replaCemenT

Level 1.

Parts Required: Pre-cut Nylon Line

1. Shut engine off. Lay unit on the ground with head assembly up.

2. Remove old nylon line through center recess of head.

3. Insert pre-cut 204 mm (8 in.) length of nylon cutting line (recom-

mended sizes 2.4 mm [.095 in.] to 3.9 mm [.155 in.]) through

outside openings of trimmer head. Minimum of 153mm (6 in.) of

line should extend from each opening. 3.9mm [.155 in.] line not

recommended for trimmers under 26cc.

NOTE

Insert cutting line ends to center of head recess to insure easy

removal of used lines.

NOTICE:

Nylon line can damage plastic shield. When installing line seg-

ments, make sure line does not curve upward toward shield.

MODELS

REQUIRED LINE SIZES

SRM-2100SB

SRM-210SB/211SB

PAS-210/211

PAS-225

PAS-230/231
SRM-2400SB

.095 - .130 in.

SRM-260SB/261SB

PAS-2601

PAS-260/261

PAS-265

.080 - .095 in.

.095 - .155 in.

C
