POWXG3010LI
EN
Copyright © 2013 VARO P a g e | 7 www.varo.com
7.2 Charging Procedure
The charging procedure starts as soon as the mains plug of the charger is plugged into a
power socket and the battery (15) is inserted into the charging compartment (14).
Thanks to the intelligent charging PCB (Protective circuit board), the charging condition of the
battery is automatically detected and the battery is charged in optimum condition.
(PCB takes into account : Over Charging/Discharging, Voltage and Current, Battery
temperature, Short-Circuit, Overload, Each Cell Unbalance (Out-put, In-put), resulting in
continuous optimum Voltage & Current when Charging or Working.
This gives longer life to the battery and always leaves it fully charged when kept in the charger
for storage.
Charge battery pack only with the charger provided.
To charge the battery:
Connect the charger to the power supply (Make sure that the power supply is 230 volts
AC/50Hz.), the red light(11) is on.
Attach the battery pack to the charger. The yellow light(12) will flash with at a frequency of
one time every two second.
When the battery is full charged, the red(11), yellow(12) and green LED(13) are all lit.
In order to charge the battery fully, the charging time must be min. 12 hours
for the first 3 charge/discharge cycles.
Please note :
With continuous or several repetitive charging cycles without interruption, the charger can
warm up. This is not harmful and does not indicate a technical defect of the unit.
A battery that is new or has not been used for a longer period does not develop its full
capacity until after approximately 5 charging/discharging cycles. Leave such batteries in
the charging compartment until they have clearly warmed up.
A significantly reduced working period after charging indicates that the batteries are worn
out and must be replaced.
8 ASSEMBLY
Do not connect the battery before your grastrimmer is completely
assembled.
8.1 Mounting the Cutting Guard (fig A)
Place the cutting guard (9) on the trimmer head.
Hook the guard onto the trimmer head and push until it fits securely
Push rear of guard until it locks (click).
8.2 Fitting Cutting Disc/Fitting Blade (fig B/C)
Press cutting disc onto drive adaptor as shown (click) in fig B.
Fit the blade, place the blade (8) over the pivot (19) and pull outwards until it snaps into
place. (fig C)
9 ADJUSTMENT
9.1 Using Adjustable Handle (fig D)
The adjustable handle (4) can be set in various positions:
To change the position undo the handle knob (3) and move the adjustable handle (4)
