POWX230
EN
Copyright © 2014 VARO P a g e | 6 www.varo.com
 It can only protect you when the power mains to which the tool is plugged is properly
grounded.
 Have the proper outlet installed by a qualified electrician.
 Check with a qualified electrician or service personnel if the grounding instructions are not
completely understood, or if in doubt as to whether the tool is properly grounded.
6.2 Diamond blades
 Only use 180mm diameter Continuous Rim Wet Diamond blades.
 DO NOT use larger, segmented or 'turbo' blades, wood sawing blades, or any other
cutting device. : Severe bodily injury, and damage to your saw can occur !
 Inspect blades daily for cracks or uneven wear. Discard cracked, chipped or bent blades!
 Ensure the blade is mounted with the rotation arrow in the proper direction and is securely
tightened with a wrench.
 Always ensure a continuous flow of water on both sides of the blade before cutting any
material.
 Do not operate the machine without all safety guards in position
 Do not force the material into the blade. Let the blade cut at its own speed.
7 ASSEMBLY
ATTENTION ! Disconnect the power plug before carrying out any
adjustments or maintenance.
7.1 Mounting of disc (fig 1a, 1b &1 c)
7.2 Assembly of dividing knife and protective guard (fig 2)
A – Safety guard
B – Dividing knife
7.3 Mounting of guard / angle guard. (fig 3)
7.4 Inserting the water reservoir (fig 4)
8 OPERATION
The base of your Tile cutter must be well positioned and firmly installed on a flat and solid
surface in an area inaccessible to children.
It must be screwed on a stable base (bench, universal base).
Insure of a strong tightening of the diamond disc between the flanges before starting.
8.1 Switching on and off
 To turn the machine ON, press the green push button.
 To turn the machine OFF, press the red push button.
8.2 Angle adjustment of the table (fig 5)
 Allows to cut a tile at 45°.
 Loosen the table locking screws on the front and back of the table.
 incline the table to the desired angle and re-tighten.
8.3 Water reservoir
 When cutting with this tool, the disc should always be in contact with water.
 When storing, remove the reservoir and clean it from sediments of cutting.
