POWX0079LI

EN

Copyright © 2014 VARO

p a g e

|

7

www.varo.com

7.2

Chargers

 Use the charger provided with the tool only to charge the battery
 Never attempt to charge non-rechargeable batteries.
 Have defective cords replaced immediately.
 Do not expose to water.
 Do not open the charger.
 Do not probe the charger.
 The charger is intended for indoor use only.

8 OPERATION

Always disconnect the battery pack from the angle grinder before making
any adjustment or attaching any accessories.

8.1

Fitting the auxiliary handle (Fig. 1)

The auxiliary handle (6) can be attached to the angle grinder in 2 different positions: left and
right.

8.2

Assembly the protective guard (Fig. 2

– 3)

1. Loosen the clip of the protective guard (7) by pulling lock lever of protective guard (1)
outward.
2. Turn the protective guard so that uncovered part of the disc is as far apart as possible from
the hand on main handle (3).
3. Fix the protection guard by pushing the lock lever

inwards

(the protective guard should no

longer be able to move).
NOTE: If the protective guard can not be fixed firmly by the lock lever (1), use a hexagon
wrench to tighten the hexagon nut.

8.3

Replacing the grinding disc (Fig. 4

– 5)

Beware

– a disc which has been used may be very hot!

 Depress and hold down the spindle lock button (2) to secure the spindle.
 Turn the shaft until it locks.
 Remove the

outer flange (a) and backing flange (b) by using the two-hole spanner

provided.

 Fit the desired disc (8) on the spindle and replace the outer flange and backing flange.

Release the spindle lock.

Important! Only ever press the spindle lock when the motor and grinding
spindle are at a standstill!

You must keep the spindle lock pressed while you change the wheel !
For grinding wheels up to approx. 3 mm thick, screw on the flange nut with the flat side facing
the grinding wheel.

8.4

Switching on / off (Fig. 6)

Before engage the ON/OFF switch button, check that the grinding disc is
properly fitted and run smoothly, the outer flange is well tightened.

 Connect the battery pack onto the angle grinder body.
