Powerplus POW63777 LAWNMOWER 173CC 530MM EN - Manual (Page 15)

POW63777
EN
Copyright © 2014 VARO P a g e | 15 www.varo.com
13 TECHNICAL DATA
Power 3000 W
Speed at max. Power 3000 min
-1
Self Propelled Yes
Engine Displacement / type 173 cc, OHV, 4-Stroke engine
Deck material / size Steel, 530 mm
Blade Width 530 mm
Height adjustment: (7 pos ) 18.8-25.8-35.8-45.8-55.9-65.8-76.2 mm
Central height adjustment Yes
Rear discharge Yes
Grass collect bag volume 75 l
Function Collecting, mulching, rear discharge, side
discharge
Wheel diameter :
Front : 203 mm
Rear : 279 mm
Fuel Tank Capacity 1.0 l
Oil tank capacity 0.6 l
14 NOISE
Noise emission values measured according to relevant standard. (K=3)
Acoustic pressure level LpA 84 dB(A)
Acoustic power level LwA 98 dB(A)
ATTENTION! Wear hearing protection when sound pressure is over 85
dB(A).
aw (Vibration): 5.4 m/s² K = 1.5 m/s²
15 STORAGE
The same fuel must not remain in the tank for more than one month. Thoroughly clean the
mower and store it indoors in a dry place.
16 WARRANTY
 This product is warranted as provided by law for a 24 months period effective from the
date of purchase by the first user.
 This warranty covers all material or production flaws excluding : batteries, chargers,
defective parts subject to normal wear & tear such as bearings, brushes, cables, and
plugs, or accessories such as drills, drill bits, saw blades, etc. ; damage or defects
resulting from maltreatment, accidents or alterations; nor the cost of transportation.
 Damage and/or defects resulting from inappropriate use also do not fall under the
warranty provisions.
 We also disclaim all liability for any bodily injury resulting from inappropriate use of the
tool.
