POW63707 EN
Copyright © 2010 VARO P a g e | 8 www.varo.com
When you fit the top push bar you can decide the
height of the push bar by selecting the
appropriate fastening hole (Fig. 3c). Fasten the
top push bar using either the holes L for a low
position or H for a high position.
Screw the top push bar to the bottom push bar
as shown in Fig. 3d.
8 SETTING THE CUTTING HEIGHTS
Important! Adjust the cutting height only when the engine is switched off
and the power cable has been disconnected.
Before you begin to mow, check to ensure that the blade is not blunt and that none of the
fasteners are damaged. To prevent any imbalance, replace blunt and/or damaged blades. To
carry out this check, first switch off the motor and pull out the power plug.
Position Cutting depth
1 20mm
2 40mm
3 60mm
The cutting height is adjusted by “spring and bar” system. To do so, turn the equipment upside
down or tilt it to the side. Position both the front and rear axle in the same notch, so that the
cutting blade runs parallel to the lawn.
