POW63703 EN
Copyright © 2014 VARO P a g e | 7 www.varo.com
 Check the grass catcher frequently for wear or deterioration.
 Replace worn or damaged parts for safety.
7 ASSEMBLY
The lawn mower is delivered unassembled. The complete push bar must be assembled before
using the lawn mower. Follow the operating instructions step-by-step and use the pictures
provided as a visual guide to easily assemble the machine.
7.1 Preparation
 Put the cable hook on upper handle (Fig. 1a)
 Connect upper and lower handles with supplied screws and knobs. (Fig. 1b)
 Insert the handles into the mower body. (Fig. 1c)
 Fit each wheels over the axles, secure in place with
the “R” pins and press the wheel
covers into place. (Fig 1d & 1e)
 Fix the cable holders. (Fig. 1f)
 Grasse collection box assembly. Assemble two halves and fix them together. (Fig. 1g)$
 Lift the flap and place the grass box over the lugs. (Fig. 1h)
8 SETTING THE CUTTING HEIGHTS
Important! Adjust the cutting height only when the engine is switched off
and the power cable has been disconnected.
Before you begin to mow, check to ensure that the blade is not blunt and that none of the
fasteners are damaged. To prevent any imbalance, replace blunt and/or damaged blades. To
carry out this check, first switch off the motor and pull out the power plug.
To obtain the desired cutting height, the front and rear axles are repositioned on the underside
of the mower housing.
Warning! Disconnect the mower from the power supply and ensure the
blade has stopped coasting before adjusting the height.
8.1 To adjust the front wheel cutting height position (fig. 2a)
 Turn the mower upside down.
 Pull the wheel axle towards the front of the mower.
 Locate the wheel axle into the desired cutting height adjustment position.
Note: Make sure that both front right and left wheels are located in the same
cutting height adjustment position.
8.2 To adjust the rear wheel cutting height position (fig. 2b)
 Turn the mower on its side.
 Pull the rear wheel axle towards the mower
’s catcher flap.
 Locate the wheel axle into the desire cutting height adjustment position.
Note: Make sure that both rear right and left wheel are located in the same
cutting height adjustment position.
8.3 Cutting height positions (fig.2c)
 25 mm (lowest cutting height position)
 40 mm
 55 mm (highest cutting height position)
