POWAIR0340 EN
Copyright © 2011 VARO P a g e | 6 www.varo.com
9 TECHNICAL DATA
Model POWAIR0340
Activation mode Single sequential action
Max. allowable pressure 120PSI(8.3 bar)
Operating pressure 60-100PSI(4-7bar)
Air inlet size ¼”
Avg. air consumption 124.84l/min (4.41cfm)
Recommended lubricant White mineral oil
Nail capacity 60pcs
10 TROUBLESHOOTING
SYMPTOM PROBLEM SOLUTIONS
Air leak
near top of tool or in
trigger area 1. O-ring in trigger valve is
damaged.
2. Trigger valve head are
damage.
3. Trigger valve stem, seal or
O-ring are damaged. 1. Check and replace O-ring.
2. Check and replace.
3.Check and replace trigger
valve stem, seal or O-ring
Air leak near bottom of
tool. 1. Loose screws.
2. Worn or damaged O-rings
or bumper. 1. Tighten screws.
2. Check and replace O-rings
or bumper.
Air leak between body
and cylinder cap. 1. Loose screws.
2. Worn or damaged O-rings
or seals. 1. Tighten screw.
2. Check and replace O-rings
or bumper.
Blade driving fastener
too deep. 1. Worn bumper.
2. Air pressure is too high. 1. Replace bumper.
2. Adjust the air pressure.
Tool does not operate
well: can not drive
fastener or operate
sluggishly. 1. Inadequate air supply.
2. Inadequate lubrication.
3. Worn or damaged O-rings
or seals.
4. Exhaust port in cylinder
head is blocked. 1. Verify adequate air supply.
2. Place 2 or 6 drops of oil
into air inlet.
3. Check and replace O-rings
or seal.
4. Replace damaged internal
parts.
