POWXQ5223 EN
Copyright © 2014 VARO NV Page | 7 www.varo.com
8.2.1 Impact drilling mode: (Fig. 1)
The tool produces an impact force while turning, suitable for masonry drilling, such as drilling
on concrete and bricks.
Make sure the drill is forced against the work piece before starting the tool.
8.2.2 Chiseling mode : (fig. 2)
The tool produces only impact force, suitable for chiseling on concrete and bricks.
Avoid using the chisel as a lever to pry!
8.2.3 Drilling only mode : (Fig. 3)
The tool only has turning action, suitable for drilling on metal and non
– metal objects.
8.2.4 Idle running mode: (forbidden!!) (Fig. 4)
The tool produces no action with the motor runs idly, this mode is forbidden as this is harmful
for the motor.
9 CLEANING AND MAINTENANCE
Before performing any work on the equipment, pull the power plug.
9.1 Cleaning
 Keep the ventilation slots of the machine clean to prevent overheating of the engine.
 Regularly clean the machine housing with a soft cloth, preferably after each use.
 Keep the ventilation slots free from dust and dirt.
 If the dirt does not come off use a soft cloth moistened with soapy water.
 Never use solvents such as petrol, alcohol, ammonia water, etc. These solvents may
damage the plastic parts.
Make sure no water can reach the inside of the power tool!
9.2 Replacing coal brushes
Remove and check the carbon brushes regularly. Replace when they have worn down to the
limit mark. Keep the carbon brushes clean and free to slip in the holders. Both carbon
brushes must be replaced at the same time. Only use original carbon brushes.
9.3 Maintenance
Our machines have been designed to operate over a long period of time with a minimum of
maintenance. Continuous satisfactory operation depends upon proper machine care and
regular cleaning.
9.4 Mains cable and plug
If the connecting cable (or mains plug) is damaged, it must be replaced. Replacement of the
connecting cable should only be carried out by a qualified specialist (qualified electrician).
10 TECHNICAL DATA
Nominal Voltage 230-240V ~ 50 Hz
Power rating 1500W
Hammering frequency 3900min-1
