‘STORE’ key again. You will hear a confirming
beep and “COUNTRY STORED” will briefly appear
on the display. The ‘VFO’ softkey indicator will
return to reverse video indicating that normal
VFO mode has been restored.

To store a memory channel from COUNTRY mode, first
enter COUNTRY mode by pressing the ‘COUNTRY’ soft-
key. Then proceed as follows:
(A.) Select an empty COUNTRY channel number using

the ‘TUNING’ knob, or the ‘< SELECT >’ keys.

(B.) Press the ‘TUNE’ softkey. This will return you to the

VFO mode. Select the mode for the frequency
range that contains the frequency you wish to
store. For example, ‘FM’, ‘MW / LW’, or ‘SW
BAND’.

(C.) Use the ‘TUNING’ knob or the ‘< SELECT >’ keys

to tune in the desired frequency, and use the
Function softkeys (except for FM mode) to set the
parameters as desired.

(D.) Press the ‘STORE’ key. This will take you back to

COUNTRY mode with the curser still on the chan-
nel number you selected previously. Press the
‘STORE’ key again. You will hear a confirming
beep and “COUNTRY STORED” will briefly appear
on the display. The ‘VFO’ softkey indicator will
return to reverse video indicating that normal VFO
mode has been restored.

RECALLING A COUNTRY CHANNEL
To select a specific COUNTRY channel, press the
‘COUNTRY’ softkey to enter COUNTRY mode. This will
cause the ‘COUNTRY’ softkey label to appear in
reverse video. Then use the ‘TUNING’ knob or the ‘<
SELECT >’ key to scroll through the COUNTRY numbers.

Note that pressing the ‘FAST / TUNING LOCK’ key
will cause ‘TUNING’ knob to advance through the
channels ten at a time instead of one at a time. For
this to occur, you must start moving the ‘TUNING’
knob within 3 seconds of pressing the ‘FAST / TUNING
LOCK’ key. Pressing the ‘FAST / TUNING LOCK’ key will
NOT, however cause the ‘< SELECT >’ key tuning rate
to change. It will continue to scroll through COUNTRY
channels ten channel numbers at a time.

If you know the number of the COUNTRY channel you
want to receive, you can go to it directly by entering
the number on the ‘Direct- Key-Input’ keypad. If less than
a four digit number is entered, there may be a slight delay
between the time you enter the number and the time the
channel change actually takes place. However, if you enter
a four digit number, the channel change will occur imme-
diately upon entry of the fourth number.

COUNTRY FUNCTIONS continued

MANUAL

Example: To enter COUNTRY channel 765, press ‘0',
‘7', ‘6', ‘5'.

If you want to temporarily change a parameter of a
received COUNTRY channel, or simply want to “tune
around” the stored frequency, there are two ways to
do this.

The first method is simply press any of the Function
softkeys below the display which are labeled in reverse
video, or the ‘FM’, ‘SW BAND’, or ‘MW/LW’ softkeys as
appropriate. This will return you to the VFO mode, will
cause the ‘COUNTRY’ softkey to be displayed in normal
video, and will allow you to tune the frequency,
change parameters, or change bands. To return to
scrolling through COUNTRY channels with the ‘TUN-
ING’ knob, simply press the ‘COUNTRY’ softkey again.
The other method is to press the TUNE’ softkey. This
will return the receiver to the VFO mode and will trans-
fer the COUNTRY channel frequency and all associated
parameters to the VFO for further tuning.

DELETING A COUNTRY CHANNEL
Select the COUNTRY channel to be deleted as
described in “RECALLING A COUNTRY CHANNEL”.
Press and hold the ‘DELETE’ key for 3 seconds. A high
pitched beep will be heard to indicate that the con-
tents stored in the selected memory channel number
have been deleted, and you will see the frequency dis-
appear from the selected MEMORY channel number.

CHANGING OR ADDING COUNTRY NAMES
You can add to or modify the country names. To do so
proceed as follows:
• Press the ‘COUNTRY’ softkey and use the ‘TUNING

’knob or ‘< SELECT >’ keys to select the named ten
channel block the name of which you wish to
change or name. Note that each ten channel block
begins with on 1 and ends on 10. For example, 501
- 510, 1691 - 1700. The reverse video curser can be
on any number within the selected block of ten.

• Press and hold the ‘COUNTRY’ softkey for 3

seconds. “EDIT NAME” will appear on the display,
and a flashing curser( “ _ “) will appear.

• Within 3 seconds, use the ‘TUNING’ knob to select

the first letter of the new name, and press the right
‘< SELECT >’ key to advance the curser to the
position of the next letter or number to be added.

• Proceed in this manner until the full name of the

country has been entered.

• When all of the desired alphanumerics have been

added, press the ‘STORE’ key. You will hear a con
firming beep, and “COUNTRY STORED” will appear
briefly on the display.

COUNTRY FUNCTIONS continued

COUNTRY channels can be scanned using the SEEK
function which can stop on any stored channel that
has a predetermined signal level. With COUNTRY
channels programmed with a “T” tag, you can use the
T.SCAN function to selectively monitor desired
COUNTRY frequencies. The following operating
parameters may be stored in any COUNTRY channel:
(1) Frequency, (2) Mode, (3) Bandwidth, (4)
AGC setting, (5) PBT setting, (6) Synchronous
Detector setting.

THE COUNTRY DISPLAY
Please refer to the numbered figure above.
(1)

Channel Frequency - This is the frequency that is
stored in the selected COUNTRY channel.

(2)

COUNTRY - This indicator identifies the screen as
a COUNTRY display as opposed to a MEMORY
display.

(3)

T - This indicator marks this channel as being one
selected for T.SCAN. T.SCAN searches through all
COUNTRY channels marked with the “T” and will
ignore all others. T.SCAN will stop on any channel
marked with a “T” which has a signal strength
greater than the SQUELCH setting. It will proceed
to the next marked channel either based on a 5
second time interval, or will stay on the channel it
stopped on until the ‘T.SCAN’ key is pressed
again. Which of these T.SCAN methods is used is
determined by the setting of item 2 in the RADIO
SETTINGS menu. The “T” tag is added to or
removed from the COUNTRY channel on which
the curser rests by pressing the ‘TAG’ key.

(4)

Curser - This reverse video segment identifies the
selected COUNTRY channel. This Curser is moved
up or down through the ten displayed channels
one at a time using the ‘TUNING’ knob or a page
at a time (10 channels) using the ‘
