3-20 Elo Entuitive Touchmonitor User Guide
Side Bezel Buttons
Control Function
1 MENU Menu Display/Exits the OSD menus.
2 Up Brightness/ 1. Adjust contrast of the OSD.
Plus/Clockwise 2. Increase value of the adjustment item.
3. Select item clockwise.
3 Down Minus 1. Adjust audio volume of the OSD.
2. Decrease value of the adjustment item.
Counter-clockwise 3. Select item counter-clockwise.
4 AUTO/SEL Enter Select item Select- To select the adjustment items from the OSD
menus. Auto- To activate the “A uto Adjustment”
function to obtain an optimum image.
5 Power Switch Switches on/off the power of your touchmonitor.
Enable/Disable 1. Press the Menu and buttons at the same time
and hold for two seconds to enable/disable the OSD
functions. OSD menu default is enabled.
2. Press the Menu and buttons at the same time
and hold for two seconds to enable/disable the power
lock function.
1
2
3
4
5
