2-10 Elo Entuitive Touchmonitor User Guide
STEP 4-Connecting the Speaker Cable
Note:
If you do not wish to connect the speaker cable, go to step 5.
•
Connect the light blue end of the speaker cable to the light blue speaker port to the monitor (audio
in).
•
Connect the lime (light green) end of the speaker cable to the lime speaker port on the computer
(audio out)
SPEAKER CABLE
SPEAKER
PORT
CONNECTIONS ON UNDERSIDE
