SYSTEMS
SW6124BXD
SW6124BX
SW5124BX
Subwoofer Driver SW6124
× 2
SW6124
SW5124
Frequency Response
28 — 250Hz
28 — 250Hz
35 — 250Hz
Sensitivity 1W/m SPL
88dB
85dB
88dB
Normal Impedance
8
Ω + 8Ω Parallel = 4Ω
4
Ω
4
Ω
Dimensions (W
× H × D) 27.6˝ Ч 13.8˝ Ч 15.3˝ (701 Ч 350 Ч 389mm) 14.7˝ Ч 13.9˝ Ч 15.3˝ (373 Ч 353 Ч 389mm) 18.9˝ Ч 15˝ Ч 8˝ (480 Ч 381 Ч 203mm)
Weight (Gross)
51.8lbs (23.5kg)
30.8lbs (14kg)
26lbs (11.8kg)
Weight (Net)
51.3lbs (23.3kg)
30.5lbs (13.9kg)
25.5lbs (11.6kg)
Finish
Grey & Black Vinyl
Grey & Black Vinyl
Grey & Black Vinyl
Continuous Power Handling
500W
250W
125W
Maximum Power Handling
1000W
500W
250W
SW5124BX
12˝ Truck-box Subwoofer System
• RMS power handling: 125W
• Max. power handling: 250W
SW6124BXD
12˝
× 2 Subwoofer System
• RMS power handling: 500W
• Max. power handling: 1000W
• Single 4
Ω terminal
SW6124BX
12˝ Subwoofer System
• RMS power handling: 250W
• Max. power handling: 500W
ECLIPSE subwoofer systems are constructed
from sturdy wood, carefully assembled and
well-damped for a tight bass. Finished in
attractive and durable vinyl, these subwoofer
systems are ready for final installation.
Featuring a configuration specifically designed for the
installation space requirements of trucks, SUVs and similar
vehicles, the SW5124BX incorporates a special low-profile
bass driver that saves space and still delivers a massive low
frequency sound.
Cutaway view of the SW5124 Lo-Profile Custom
Application Woofer shows the significantly reduced
depth of this speaker that makes it an ideal choice to
install in a truck-box enclosure.
Speaker Grill
Speaker Grill
