PSB No: P-0060
Page: 2 of 2
Product Voltage
Max. Current
Consumption Power Consumption BTU/HR
LX810 120V .7 Amp 84 VA maximum
I
286.69
T750 120V 1.0 Amp 120 VA maximum 409.56
T1OOO 120V .7 Amp 84 VA maximum 286.69
If the power requirements of a particular Epson printer is not listed please
refer to the appropriate User's Manual for the electrical specifications.
In the event that the User's Manual is not available, locate the silver label
on the back of the Epson printer. This is a reliable source for the electrical
requirements. The following formula is used to calculate the electrical
power requirements:
VOLTAMPS is equivalent to WATTS
VOLTAMPS = Volts * Amps
AMPS
BTU/HR
= Voltamps/Volts
= Watts * 3.413
Example:
120V * 1A = 120VA
120VA/120V = 1A
120VA is equivalent to 120W
120W * 3.413 = 409.56 BTU/HR
Heat output is rated in BTU/HR.
