COMPONENT IDENTIFICATION
Note: These drawings represent only the major components of the system; the position of the components may vary depending on the bath model.
Note: These drawings represent Combined Systems; Whirlpool Systems components are identified with “
1
” and Air Systems
components are identified with “
2
”.
TRUE WHIRLPOOL
®
&
AEROFEEL
®
TRUE WHIRLPOOL
®
&
AEROEFFECT
®
4
Manifold
2
Electronic Box
1-2
Electronic Control
1-2
Water detector and
temperature probe
1-2
Blower
2
Whirlpool Pump
1
*Heated Backrest
2
Chromotherapy
Light
*Back Jets
1
Diverter Valve
1
(Back jets)
Air Control
1
Safety Suction
1
Whirlpool Jet
1
Water Heater
2
Cable Operated
Drain and Overflow
*Air Back Jets
2
Air Injectors
2
Manifold
2
Electronic Box
(Chromotherapy light)
Electronic Control
1-2
Blower
2
Whirlpool Pump
1
*Heated Backrest
2
Chromotherapy
Light
*Back Jets
1
Diverter Valve
1
(Back jets)
Air Control
1
Safety Suction
1
Whirlpool Jet
1
Water Heater
1
Cable Operated
Drain and Overflow
Chromotherapy
Control
Air Injectors
2
*When the Back Jets Option is selected, the Air Back Jets and
the Heated Backrest will be replaced by the Whirlpool Back Jets.
*When the Back Jets Option is selected, the Heated Backrest will
be replaced by the Whirlpool Back Jets.
