20
Installation Instructions and Owner’s Manual Unvented Natural Gas Fired Room Heater
1 70300 70300 70300 Cabinet Assembly 1
1-1 70301 70301 70301 Cabinet Top Panel 1
1-2 70302 70302 70302 Cabinet Right Panel 1
1-3 70303 70303 70303 Cabinet back Panel 1
1-4 70304 70304 70304 Cabinet Left Panel 1
2 70305 70305 70305 Lower Front panel assembly 1
3 70312 70312 70312 Reflector Assembly 1
4 --- 70319 70319 Burner Assembly 1
5 70320 70320 70320 Wall Mounting Bracket 1
6 70321 70321 70321 Valve Mounting bracket 1
7 70322 70322 70322 Bezel – Reflector Front 1
8 70323 70324 70324 Valve / Piezo Assembly 1
10 70325 --- --- Back Plate 1
13 70338 70338 70338 Pressure regulator 1
14 --- 70326 70326 Glass 1
15 --- 70327 70327 Glass Mounting Bracket 1
16 70365 70365 70365 ODS / Pilot Assembly 1
16-1 part of #16 part of #16 part of #16 Thermocouple **
16-2 part of #16 part of #16 part of #16 Ignition Electrode **
21 70655 --- --- ODS mounting bracket 1
22-1 70396 70396 70396 Heat Shield – Top 1
22-3 70330 70331 70331 Heat Shield – Back 1
23 70663 70663 70663 Regulator Mounting Bracket 1
24 70665 70665 70665 Floor mount feet 2
26 70332 70332 70332 Grill guard 1
27-1 70333 --- --- Orifice, IR 2
27-2 —- 70393 70334 Orifice, BF 1
35 70336 --- --- Bracket, Top, Plenum, Assembly 1
36 70336 --- --- Bracket, Bottom, Plenum Assembly 1
38 70677 --- --- Burner Plaques, 10 2
40 70678 --- --- Plaque Gasket, 10 2
42 70337 70337 70337 Control Valve Knob 1
43 70318 --- --- Plenum Assembly 1
44 70597 70597 70597 3/8” FTP x 3/8” MPT Elbow
* 70352 --- --- Right Burner gas tube 1
* 70353 --- --- Left burner gas tube 1
* 70354 70354 70354 ODS Gas Tube Assembly 1
* 70355 70355 70355 Regulator to Thermostat Valve tube Ass’y 1
* 70342 70342 70342 * Hardware kit 1
* 70347 70348 70348 * CSA label 1
* 70349 70349 70349 * Gas Instruction decal 1
* 70350 70350 70350 * Inside warning label 1
IR10NG, BF6NG and BF10NG • PARTS LIST
This list contains replacement parts used in your heater. When ordering parts, follow the instructions listed
under Replacement Parts on page 20 of this manual.
ITEM PART NO. DESCRIPTION QTY.
IR10NG BF6NG BF10NG
* Item Not Shown ** Must purchase assembly
