Build-in model
To install the appliance in a kitchen cabinet, use the
appropriate mounting frame. Note the relevant instruc-
tions for installation and connection. When building in to
a high cabinet, you may use the liftdoor. Note the rele-
vant information for installation and connection given in
the operating instructions of the lift door.
Warning !
Never operate the microwave oven with the lift door
closed. Such operation would damage your appliance
and invalidate the guarantee.
Connect to a plug socket with protective earth contact
and fused with a 13 A-L automatic device or 13 A slow-
blowing fuse. When the oven is installed, there must be
a possibility of disconnecting it from mains with a
contact break of at least 3 mm on all poles.
A suitable size of LS-switch, or a melting or fly-out fuse,
are suitable contact-breakers.
31
E EM MS S 2 24 48 85 5 U UK K
Building in kit BF 246
Overall dimension Width 540 mm
Depth 416 mm
Height 316 mm
Cavity Width 350 mm
Depth 351 mm
Height 210 mm
Volume 24 l
Power source 230-240 V, 50 Hz
Fuse 13A
Power consumption
(microwave + grill)
2750W
Power Output 900W
Grill 1250W
Weight 19 kg
MAFF Rating E
Technical data
The plug moulded on to the lead incorporates a fuse. For
replacement, use a 13 Amp BS1362 fuse. Only ASTA or
BSI approved fuses should be used.
The plug must not be used if the fuse cover/carrier is
lost. The cover/carrier is indicated by the coloured insert
at the base of the plug.
A replacement cover/carrier is indicated by the coloured
insert at the base of the plug.
A replacement cover/carrier must be obtained from your
local Electrolux Service Centre.
This appliance complies with E.E.C. directive No.
87/308 of 2.6.87 relative to radio interference suppres-
sion.
Connecting to the mains
The oven is delivered with the power cord and a plug for
240 V, 50Hz, earthed socket outlet.
Earth protection minimizes the risks should a short-cir-
cuit occur. Check to ensure the voltage of the oven mat-
ches the supply.
N.B. If the oven is connected to the socket via an exten-
sion cord, make sure the cord is earthed.
Thi s applianc e must not be used on a nonearth
protected power supply. Contact an electrician if
you are uncertain regarding electrical connection
of the oven or provision of earth protection of the
supply.
This appliance must be earthed. If this appli-
ance is fitted with a non-rewirable plug for which
your socket is unsuitable, the plug should be
cut off and the appropriate plug fitted. If it is
necessary to change the fuse in a nonrewirable
plug, the fuse cover must be refitted. If the fuse
cover is lost or damaged, the plug must not be
used until a replacement is obtained.
!
