1.3 Specifications
Pickup Device
1/2.5" 2 megapixel CMOS sensor
Sensitivity 0.02lux/F=1.2(AGC
ON)
S/N Ratio
Greater than 50dB (AGC off)
Video Format Main Output
HD-SDI/HD-CCTV
Resolution Main Output
1920x1080/2 Megapixel/1080i or 1280x720/1 Megapixel/720p
Video Mode Main Output
Field select 1080i or 720p
Main Output Connector
BNC-F
Video Format Test Output
NTSC/PAL selectable 1V p-p
Test Output Connector
RCA-F
Electronic Shutter
1/60(1/50)~1/8000
Lens Type
CS mount (Adapter included for C-mount; lens sold separately).
Lens Control
Supports DC or manual lens
Back Light Comp.
On/Off selectable
Auto Gain Control
High/Middle/Low/Off selectable
Auto White Balance
AWB/One Push WB/Manual WB/Indoor/Outdoor
Gamma Correction
0.45 nominal, adjustable 0.05~1.00
Iris Control
Auto, -2.0EV~2.0EV
OSD Menu
Yes (controlled from rear 5-axis joystick control)
True Day/Night Control
Yes (Auto IR cut filter removal)
H-Mirror Yes
Power Source
12VDC/24VAC
Power Consumption
24VAC: 6W max.
12VDC: 6W max.
Dimensions (incl. BNC)
68mm(W) x 56mm(H) x 146mm(D) ; 2.7"(W) x 2.2"(H) x 5.7"(D)
Weight
0.4 kg ; 0.9 lbs
Operating Temperature
0°C~45°C ; 32°F~113°F (20%~80% Humidity)
Certifications FCC/CE
1.4 Dimensions
