A. BOTTOM PANEL CONTROL
1. HDMI IN
2. DVI IN
3. VGA(D-SUB) IN
4. PC STEREO IN
5. AUDIO OUT(Speaker)
6. COMPONENT Y,Pb,Pr & SOUND L,R IN
7. DC 12V IN
8. TRIGGER INPUT
B. SIDE PANEL CONTROL
1. VIDEO1(AV1) IN
2. VIDEO1(AV1) OUT
3. VIDEO2(AV2) IN
4. VIDEO2(AV2) OUT
5. S-VIDEO(Y/C) IN
6. S-VIDEO(Y/C) OUT
7. AV1 & S-VIDEO AUDIO IN
8. AV1 & S-VIDEO AUDIO OUT
9. AV2 AUDIO IN
10. AV2 AUDIO OUT
11. DC 12V ADAPTOR
7 6 5 4 3 2 1 8
1
2
3
4
5
6
7
9
8 10
11
