Channel
Function
Time and Value
DMX
HEX
%
Gobo rotation, slow-fast, CW
Min. 1.4 turns/h
130..191 82..BF
51..75
Gobo rotation, fast-slow, CCW
Max. 1.0 turns/sec.
192..253 C0..FD 76..98
Audio gobo chase, slow
Each 4
th
sound impulse
new gobo
254
FE
99
Audio gobo chase, fast
Each sound impulse
new gobo
255
FF
100
12) Shutter Shutter closed
0..15
00..0F
0..6
Random Strobe (different pattern)
16..31
10..1F 7..11.9
Strobe Pulse effect, slow - fast
Min. frequency 0.7 Hz
32..47
20..2F 12..12.9
Audio Shutter
48..63
30..3F
13..25
Strobe effect, slow - fast
Max. frequency 10 Hz
64..239
40..EF
26..93
Shutter open (lamp start)
240..255 F0..FF 94..100
13) Dimmer Dimmer closed (0%)
0..3
0..3
0..1
Dimmer 1%...99%
Movement time 0.3 sec.
4..251
4..FB
2..98
Dimmer open (100%)
252..255 FC..FF 99..100
14) Focus
In (near) - out (far)
Full distance 1.5 sec.
0..255
0..FF
0..100
15) Zoom
Inside (near) - outside (far)
Full distance 1.5 sec.
0..255
0..FF
0..100
16) Frost
Open (0%) - retracted (100%)
Full distance 1.5 sec.
0..255
0..FF
0..100
17) Prism
Prism swing out
0..5
00..05
0..2
Prism position 0 ... 540°
6..129
06..7F
0..50
Prism rotation stop
130..191 80..BF
51..75
Prism rotation, slow-fast, CW
Min. 1.6 turns/h
192..253 C0..FD 76..100
Prism rotation, fast-slow, CCW
Max. 4.4 turns/sec.
254
FE
99
Audio prism rotation, slow
Each 4
th
sound impulse
new prism
255
FF
100
18) Iris
Iris open – closed
0..127
00..7F
00..49
Ascend with Shutter, random
128..143 80..8F
50..56
Descend with Shutter, random
144..159 90..9F
56..62
Ascend with Shutter, audio
160..175 A0..AF
63..68
Descend with Shutter, audio
176..191 B0..BF
69..74
