52
GB
4. Switch lock: Bring direction switch
to neutral position.
Direction switch may only be activat-
ed at a standstill to prevent damage
to the transmission.
Inserting/replacing bits
Prior to commencing any work on the
device, bring the direction switch
( 9) to the neutral position in order
to prevent an accidental start up.
1. Insert the desired bit (14) or bit
holder (15) into the bit adapter
(11). It locks into place audibly.
2. To remove the bit or bit holder
pull the spring sleeve (1) back.
3. With the spring sleeve (1) pulled
back remove the bit or bit holder
from the bit adapter (11). Release
the spring sleeve.
Torque setting
Always turn off the device, before
setting the torque.
1. Turn the adjusting ring (2) to se-
lect the desired torque:
Step 1 --> lowest torque,
Step MAX --> highest torque
(4 Nm).
Screws: Steps 1 - 6
Drilling: Step MAX.
2. Start with a lower torque step and
increase according to requirement.
The necessary torque is dependent on:
- the type and hardness of the
material to be treated;
- the type and length of the
screws used.
Handle setting
Prior to commencing any work
on the device, bring the direction
switch ( 9) to the neutral position
in order to prevent an accidental
start up.
The device can be locked in two hand set-
tings:
- Pistol grip position
- Rod position
Press the release key PRESS (4) and
turn the handle (6) of the device by
180°. It locks into place audibly.
Use as a torch
1. Press the torch lens (5) on the
underside of the handle (6). The
torch LEDs light up.
2. To switch off the LEDs press the
torch lens (5) again.
Cleaning/Maintenance
Leave any work not covered in this
manual to our Service Centre. Only
use original parts. There is a risk of
injury!
Cleaning
Clean and service the device regularly as
follows. This guarantees a long life for your
unit:
Do not jet water onto the
appliance and do not clean
it under flowing water. This
would result in the danger of
an electric shock and the ap-
pliance could be damaged.
