Parkside PSSA 3.6 C3 - Manual (Page 45)

45
GB
General description
The illustration of the princi-
pal functioning parts can be
found on the front and back
foldout pages.
Extent of the delivery
Carefully unpack the appliance and check
that it is complete.
Dispose of the packaging material cor-
rectly.
- Cordless screwdriver
- Charger
- 26 bits
- 1 Bit holder
- Case
- Instruction Manual
26 bits:
SL
25mm 3 • 4 • 5 • 6 • 7
50mm 5
PZ
25mm 0 • 2 x 1 • 2 x 2 • 3
50mm 2
PH 25mm 0 • 2 x 1 • 2 x 2 • 3
T 25mm 10 • 15 • 20 • 25
H 25mm 3 • 4 • 5
Slot
No.
No.
No.
No.
No.
No.
No.
Cross
Cross
Torx
Hexagonal
Overview
1 Spring sleeve
2 Torque setting
3 Battery Indicator
(not visible)
4 Release key for handle setting
5 Torch
6 Handle
7 Charging socket
8 On/Off switch
9 Direction switch
10 LED work light
11 Bit adapter
12 Charging cable connector
13 Charger
14 Bits
15 Bit holder
Function description
The cordless screwdriver with clockwise/
anticlockwise rotation has 6 torque steps,
one drilling level and one LED work light.
Furthermore, the device can be used as a
torch.
Please read the following descriptions for
the function of the various controlling parts
of the unit.
