Page 19 20248-2-0806 Empire Comfort Systems, Inc. Nine Eighteen Freeburg Ave. Belleville, Illinois 62220-2623
USE ONLY MANUFACTURER'S REPLACEMENT PARTS. USE OF ANY OTHER PARTS COULD CAUSE INJURY OR DEATH.
Index Part
No. Number Description
Index Part
No. Number Description
1 20217 TRIM - TOP
2 20215 TRIM - LEFT
3 20216 TRIM - RIGHT
4 10554 NAILING FLANGE (3 REQUIRED)
5 11289 OUTER WRAPPER TOP
6 10574 CORNER BRACE 2
7 10573 CORNER BRACE 1
8 11295 OUTER WRAPPER
9 11289 OUTER WRAPPER BOTTOM
10 11460 LOUVER ASSEMBLY - UPPER
11 11462 SCREEN ASSEMBLY
12 11461 LOUVER ASSEMBLY - LOWER
13 11322 LOUVER HINGE BRACKET (2 RE-
QUIRED)
14 11296 FIREBOX TOP
15 11303 INNER FIREBOX TOP
16 11334 REAR LOG SUPPORT WELDED AS-
SEMBLY
17 11302 FIREBOX WALLS
18 11304 FIREBOX BOTTOM
20 P-253 ORIFICE FITTING - ANGLED
21 P-182 ORIFICE - LPG (20,000 BTU)
22 R-5675 AIR SHUTTER - LPG
22 R-5676 AIR SHUTTER - NAT
23 12348 BURNER ASSEMBLY - LPG
23 12347 BURNER ASSEMBLY - NAT
24 11305 VALVE / REGULATOR BRACKET
NOT SHOWN R-5668 IGNITOR WIRE
NOT SHOWN R-4459 MAGNET (2 REQUIRED)
NOT SHOWN 12389 CERAMIC MEDIA (REPAIR)
NOT SHOWN 15998 ROCK WOOL
NOT SHOWN P-251 COUPLING - NAT
VF24FP3-1 ONLY
19 R-3623 PILOT ASSEMBLY - LPG
19 R-3624 PILOT ASSEMBLY - NAT
21 P-181 ORIFICE - NAT (20,000 BTU)
29 R-5700 VALVE - NAT
29 R-5701 VALVE - LPG
30 11306 VALVE BRACKET (2 REQUIRED)
31 11307 VALVE COVER PLATE
32 R-3436 REMOTE/OFF/ON SWITCH
NOT SHOWN 11458 TUBING (VALVE TO PILOT) - LPG
NOT SHOWN 11459 TUBING (VALVE TO BURNER)
NOT SHOWN R-4579D SWITCH WIRE HARNESS
NOT SHOWN P-263 NIPPLE 8"
NOT SHOWN 15465 TUBING (VALVE TO PILOT
REGULATOR) - NAT
NOT SHOWN 15466 TUBING (PILOT REGULATOR) TO
PILOT) - NAT
NOT SHOWN R-7063 PILOT REGULATOR - NAT
VF24FP2-1 ONLY
19 R-5170 PILOT ASSEMBLY - LPG
19 R-5171 PILOT ASSEMBLY - NAT
21 P-265 ORIFICE - NAT (20,000 BTU)
21 P-266 ORIFICE - NAT (10,000 BTU)
21 P-193 ORIFICE - LPG (10,000 BTU)
29 16921 VALVE - NAT
29 16922 VALVE - LPG
26 R-2480 INLET REGULATOR - LPG
26 R-2479 INLET REGULATOR - NAT
27 16301 VALVE COVER PLATE
28 R-2313 PIEZO IGNITOR
NOT SHOWN 11465 TUBING (VALVE TO PILOT)
NOT SHOWN 11466 TUBING (VALVE TO BURNER)
NOT SHOWN 16302 TUBING (REGULATOR TO VALVE)
NOT SHOWN P-264 NIPPLE 5"
NOT SHOWN R-1720 PLASTIC CLIP
ATTENTION: When ordering parts, it is very important that part number and description of part coincide.
Parts can be ordered only through your service person or dealer. For best results, the service person or dealer should order parts through the distribu-
tor. Parts can be shipped directly to the service person/dealer.
All parts listed in the Parts List have a Part Number. When ordering parts, first obtain the Model Number from the name plate on your equipment.
Then determine the Part Number (not the Index Number) and the Description of each part from the following appropriate illustration and list. Be sure
to give all this information.
Fireplace Model Number
Part Description
Fireplace Serial Number Part Number
Type of Gas (Propane or Natural)
Do not order bolts, screws, washers or nuts. They are standard hardware items and can be purchased at any local hardware store.
Shipments contingent upon strikes, fires and all causes beyond our control.
PARTS LIST
HOW TO ORDER REPAIR PARTS
