Electrolux 726623 - Manual (Page 2)

Electrolux Blast Chillers
Blast Chillers - 28 kg
Internet: http://www.electrolux.com/foodservice
HDAA020
2012-07-26
Subject to change without notice
TROLLEY FOR 10XGN1/1 ROLL IN RACK 922130 922130
TROLLEY FOR 10X1/1 & 2/1 ROLL IN RACK 922128 922128
ROLL-IN RACK SUPPORT BC+BCF 28KG 10GN1/1 881518 881518
RILSAN COATED GRID 881061 881061
PRINTER HACCP BASIC VERS-REF.ELECR.CONTR 881532 881532
PLASTIC COATED GRID-600X400 MM 880864 880864
PAIR OF 1/1 GN AISI 304 S/S GRIDS 921101 921101
KIT TO CONVERT TO 10X1/1 SLIDE-IN RACK 922201 922201
KIT HACCP ADVANCED CONNECT. BC/BCF LW+CW 880183 880183
80 MM PITCH SIDE HANGERS 10X1/1 GAS 0VEN 922116 922116
80 MM PITCH SIDE HANGERS 10X1/1 ELE.OVEN 922115 922115
60 MM PITCH SIDE HANGERS 10X1/1 GAS OVEN 922122 922122
60 MM PITCH SIDE HANGERS 10X1/1 ELE.OVEN 922121 922121
4 WHEELS FOR BLAST CHILLERS 881097
3-POINT-SENSOR PROBE-BL.C/FREEZERS LW 880212 880212
1 SINGLE-SENSOR PROBE-BL.C/FREEZERS LW 880213
ACCESSORIES
1 SINGLE-SENSOR PROBE-BL.C/FREEZERS LW 1 1
INCLUDED ACCESSORIES
Net weight - kg. 124 114
installed-electric 1.198 0.12
Power - kW
at evaporation temperature - °C -10 -10
Refrigerant power
Refrigeration power - W 1419 1259
Refrigerant quantity - g. 1530
Refrigerant type R134a R134a
N° defrost in 24 hrs. 6 6
Compressor power - HP 1
Max load capacity - trays h 65 mm - n° 6 6
Trays type GN 1/1; 600x400 GN 1/1; 600x400
Door hinges Right Side Right Side
N° and type of door 1 1
height 1640 1640
depth/with open doors 760, 1500 770, 1450
width 760 760
External dimensions - mm
Cooling unit Built-In Remote
Gross capacity (D.I.N. 8952) - l. 210 210
UK Guide lines - chilling / freezing 28 28
NF Regulations - chilling / freezing 21.6 21.6
Productivity per cycle - kg.
Type C - 28 KG CHILLER C - 28 KG CHILLER
TECHNICAL DATA
RBC101
726622
RBC101R
726623
CONSTRUCTION
• Internal and external finishing in 304
AISI stainless steel and backpanel in
galvanized steel.
• High density polyurethane
insulation, 60 mm tickness, HCFC
free.
• Environmentally friendly: R404a as
refrigerant fluid.
• Developed and produced in ISO
9001 and ISO 14001 certified factory.
• Inner cell with fully rounded corners.
• Door equipped with removable
magnetic gasket with hygienic design.
• Motors and fan waterproof
protected IP21.
• Evaporator with antirust protection.
• Ventilator (fan) swinging hinged
panel for access to the evaporator for
cleaning.
• Automatic heated door frame.
• Thermostatic expansion valve to
optimize the cooling unit efficiency.
• Adjustable feet 150 mm high.
• Stand alone printer as accessory.
• PC connection on request, gate RS
485.
INSTALLATION
• No water connections required.
• Waste water can be plumbed into
drain, but can also be collected in an
optional waste container.
*NF HYGIENE ALIMENTAIRE
certifying authority : AFAQ AFNOR
CERTIFICATION. Adress:11, Avenue
Francis de Pressense - 93571
Saint-Denis La Plaine Cedex - France.
Conformity with regulation NF031.
Certified guarantees: fitness for
cleaning, thermal performance.
