Parkside PRESSURE WASHER ADAPTOR - Manual (Page 6)

6
Instruction Manual
Pressure washer adapter
(adapter)
Intended purpose
The pressure washer adapter is suitable
for connecting the following PARKSIDE
accessories to various devices from other
manufacturers:
• High-pressure scrubber
• Pipe cleaning set
• Surface cleaner
The pressure washer adapter is not suitable
for industrial use.
Also observe the safety instructions,
maximum and rated pressures from
the original operating instructions for
your pressure washer.
Technical specifications
Supply temperature ................Max. 40°C
Suitable for devices with the fol-
lowing performance data:
Operating pressure / Rated pressure
.........................max. 110 bar / 11 MPa
Pressure ................max. 150 bar / 15 MPa
Max. pumping rate, water .............. 450 l/h
To connect
- Fit the adapter (1) onto the connection
(2) of the PARKSIDE accessory and turn
through 90° until it clicks into place (Ba-
yonet catch).
- If applicable, tighten the retainer nut on
the PARKSIDE accessory (3).
- Connect the pressure washer (Bayonet
catch) and tighten the retainer nut (4)
on the adapter (1).
GB IE To release
- Release the retainer nut on the adapter (4)
and if applicable the retainer nut on the
PARKSIDE accessory (3).
- Release the catches by pushing and tur-
ning through 90° in the opposite direction
(Bayonet catch).
Service-Center
Service Great Britain
Tel.: 0871 5000 720
(£ 0.10/Min.)
E-Mail: [email protected]
IAN 93487
Service Ireland
Tel.: 1890 930 034
(0,08 EUR/Min., (peak)
(0,06 EUR/Min., (off peak)
E-Mail: [email protected]
IAN 93487
Service Branch
Please note that the following address is
not a service address. Please initially con-
tact the service centre specified above.
DES UK Ltd.
Unit B7
Oxford Street Industrial Park
Vulcan Road
Bilston, West Midlands WV14 7LF
GB
IE
