13118-7-0408 Page 16
PLEASE NOTE: When ordering parts, it is very important that part number and description of part coincide.
Index Part
No. Number Description
USE ONLY MANUFACTURER'S REPLACEMENT PARTS. USE OF ANY OTHER PARTS COULD CAUSE INJURY OR DEATH.
1 11762 OUTER CASING TOP
2 R-618 MOTOR MOUNT - 4 REQUIRED
3 11764 MOTOR MOUNTING BAR - 2 REQ'D
4 M-147 GASKET - 2 REQUIRED
5 R-619 MOTOR
6 11787 FAN BLADE
7 11766 FAN HOUSING
8 DV-558 FRONT PANEL- UPPER
9 11759 SIDE PANEL - 2 REQUIRED
10 DV-613 INNER SHIELD - RIGHT
11 13057 OUTLET TUBE - INNER ASSEMBLY
(INCLUDES 12 &13)
12 M-177 GASKET - OUTLET COLLAR
13 13104 OUTLET TUBE - INNER WELDED
ASSEMBLY
14 13062 INNER TUBE - INNER ASSEMBLY
(INCLUDES 15 & 16)
15 M-178 GASKET - INLET COLLAR
16 13106 INLET TUBE - INNER WELDED
ASSEMBLY
17 13064 INLET TUBE - OUTER ASSEMBLY
18 13059 OUTLET TUBE - OUTER ASSEMBLY
19 13053 VENT CAP ASSEMBLY WELDED
20 DV-1387 AIR DROP WELDED ASSEMBLY
21 M-176 GASKET - FLUE OUTLET FLANGE
22 13113 COMBUSTION CHAMBER WELDED
ASSEMBLY
23 R-1536 BUSHING
24 11765 SWITCH COMPARTMENT
25 R-630 LIMIT CONTROL
26 R-1941 FAN CONTROL
27 DV-832 SWITCH COMPARTMENT COVER
28 DV-562 FRONT PANEL - LOWER
29 DV-826 REAR BURNER ASSEMBLY
30 R-685 THERMOCOUPLE
31 R-622-L PILOT WITH ORIFICE - LPG GAS
31 R-622-N PILOT WITH ORIFICE - NAT GAS
Index Part
No. Number Description
Parts can be ordered only through your service person or dealer. For best results, the service person or dealer should order parts through
the distributor. Parts can be shipped directly to the service person/dealer.
All parts listed in the Parts List have a Part Number. When ordering parts, first obtain the Model Number from the name plate on your
equipment. Then determine the Part Number ( not the Index Number) and the Description of each part from the following appropriate
illustration and list. Be sure to give all this information.
Furnace Model Number
Part Description
Furnace Serial Number Part Number
Type of Gas (Propane or Natural)
Do not order bolts, screws, washers or nuts. They are standard hardware items and can be purchased at any local hardware store.
Shipments contingent upon strikes, fires and all causes beyond our control.
Empire Comfort Systems, Inc. Nine Eighteen Freeburg Ave. Belleville, IL 62220-2623
32 DV-808 PILOT TUBING
33 DV-824 FRONT BURNER ASSEMBLY
34 P-88-41 ORIFICE - NAT GAS - 2 REQUIRED
34 P-88-53 ORIFICE - LPG GAS - 2 REQUIRED
35 DV-687 MANIFOLD
36 M-148 GASKET - MANIFOLD
37 M-155 GASKET-OBSERVATION HOLE COVER
38 DV-781 LIGHTING HOLE COVER ASSEMBLY
39 DV-064 COVER PLATE-OBSERVATION HOLE
40 DV-775 SEAL BRACKET
41 M-147 GASKET - TUBING SEAL
42 DV-622 BURNER DOOR - NAT GAS
42 DV-973 BURNER DOOR - LPG GAS
43 DV-779 GASKET - BURNER DOOR
44 P-112 MANIFOLD UNION
45 R-5655 GAS VALVE - LPG GAS
45 R-2148 GAS VALVE - NAT GAS
46 UH-810 TRANSFORMER MOUNTING BRACKET
47 R-1995 TRANSFORMER
48 UH-451 JUNCTION BOX COVER
49 11760 OUTER CASING BOTTOM
50 R-1515 BUSHING
51 R-2708 PIEZO IGNITOR
52 DV-571 CONTROL COMPARTMENT DIVIDER
53 DV-671 MANIFOLD SUPPORT
54 DV-765 GASKET - CHAMBER AIR INLET (TOP &
BOTTOM) - 2 REQUIRED
55 DV-764 GASKET - CHAMBER AIR INLET (SIDES)
- 2 REQUIRED
56 R-690-B CORD SET
57 R-1404 BUSHING
58 DV-614 INNER SHIELD - LEFT
NOT SHOWN R-9832 WIRING ASSEMBLY UPPER
NOT SHOWN R-9833 WIRING ASSEMBLY LOWER
NOT SHOWN R-6389 THERMOSTAT
NOT SHOWN R-734 LIGHTER ROD
HOW TO ORDER REPAIR PARTS
PARTS LIST
