40 GB
Before first use / First use
Q
Before first use
DANGER OF INJURY!
Switch the device off and pull the plug out of the
mains socket before carrying out any work on the
device.
Q
Attaching the auxiliary handle
NOTE: For safety reasons this tool must always be
used with the auxiliary handle
10 in place.
Turn the wing screw 9 anti-clockwise and swivel
the additional handle 10 into the desired position.
Then tighten the wing screw 9 again.
Q
Using the depth stop
Open the wing screw 9 .
Make sure that the toothing on the depth stop 8
is pointing downwards.
Pull the depth stop 8 out as far as necessary
so that the distance between the tip of the drill
and the tip of the depth stop corresponds to
the desired drilling depth.
Firmly tighten the wing screw 9 .
Q
Inserting tools
Quick-action drill chuck:
Take firm hold of the back casing 3 of the
quick-action drill chuck 1 and turn the front
casing 2 until the tool can be inserted.
Insert the tool.
Take firm hold of the back casing 3 of the
quick-action drill chuck 1 and turn the front
casing 2 firmly shut.
Assembly tools for screws and nuts:
When using screwdriver bits, always use a
universal bit holder.
To screw things in, always switch the changeover
switch “drill / percussion drill”
4 to the right to
position .
Q
First use
Q
Switching on and off
When operating the hammer-action drill you can
select between intermittent or continuous operation
mode. In either mode the device functions as follows:
To switch on intermittent operation mode:
Press the ON / OFF switch 6 .
To switch off intermittent operation mode:
Release the ON / OFF switch 6 .
Switching continuous operation on:
Press and hold the ON / OFF switch 6 down
and press the locking button 5 .
To switch off continuous operation mode:
Press and then release the ON / OFF switch 6 .
Q
Infinitely adjustable
speed setting
The ON / OFF switch 6 has a variable speed control.
Pressing the ON / OFF switch 6 increases the
speed.
Q
Setting the direction of rotation
With the rotational direction switch 7 you can
change the rotational direction of the electrical
tool.
NOTE: This is, however, not possible when the
ON / OFF switch
6 is pressed down.
NOTE: Hold the appliance in the direction of work.
clockwise rotation:
Push the rotational direction switch 7 to the
Left in order to drill and to screw in screws.
Anticlockwise rotation:
Push the direction of rotation switch 7 to the
right to slacken a screw or screw it out.
