36 GB/MT
j Mount the double grinding machine on a firm,
level surface, if at all possible on a fixed sup-
port, e.g. working surface, workbench. Use the
four mounting holes
8 and suitable fixings
(not supplied). Refer to Figure C.
Q
Positioning the workpiece / tool
rests and eye guard mounts
To ensure safe working, the workpiece / tool rests 5 ,
the eye guards 3 and the eye guard mounts 2
must be correctly positioned.
j Check and correct the settings at frequent intervals
to ensure even wear on the grinding wheels
4 .
Adjusting the workpiece / tool rests:
1) To adjust the setting, first loosen the adjuster
screw 6 .
2) Bring the workpiece / tool rest 5 close up to
the grinding wheel 4 , the distance between
the grinding wheel 4 and the workpiece /
tool rest 5 must be no more than 2 mm.
3) Retighten the adjuster screw 6 and check
using your hand that the grinding wheel 4
movement is true and free.
Adjusting the eye guard mounts:
1) To adjust the setting, first loosen the fastening
screw 14 .
2) Bring the eye guard mount 2 close up to the
grinding wheel 4 , the distance between the
grinding wheel 4 and the eye guard mount 2
must be no more than 2 mm.
3) Retighten the fastening screw 14 and check
using your hand that the grinding wheel 4
movement is true and free. A worn out grinding
wheel
4 needs to be replaced. This is necessary
when the specified gap cannot be achieved even
after readjusting the positions of the workpiece /
tool rest
5 and / or the eye guard mount 2 .
Q
Preparing for first use
Q
Switching on and off
Switching on:
j Press the On / OFF switch 9 into the “I“
position to switch the device on and run it
at a constant speed.
Switching off:
j Press the On / OFF switch 9 into the “0“
position to switch the device off.
Q
Grinding a workpiece
NOTE: Use the fine grinding wheel for precise
grinding tasks (grade “A80M”).
NOTE: Use the coarse grinding wheel for rough
grinding tasks (grade “A36M”).
j Switch on the machine as described above.
j To grind metal tools or metal items, place the
workpiece on the workpiece / tool rest
5 and
slowly bring it up to the grinding wheel 4 .
j Press the workpiece carefully against the grind-
ing wheel
4 . Pressing too hard can overload
the device. When grinding always use the
circumferential end face (not the sides) of the
grinding wheel only (See Figures D, E, F).
Q
Replacing a grinding wheel
RISK OF INjURy! Before
carrying out any tasks on the device itself and
when you are not using the device, always pull the
mains plug out of the mains socket.
J Do not use damaged grinding wheels.
J Only use grinding wheels with details that cor-
respond with those given on the device rating
plate. The circumferential speed should be
equal to or greater than the value given on the
device rating plate.
j Only grinding wheels with markings indicating
the manufacturer, the type of adhesive, dimen-
sions and permitted circumferential speed are
