EPSON Equity 4+

System Memory Map

23FFFFF

Extended memory

System BIOS

(Shadow RAM, 64KB)

OOEOOOO

Reserved for system BIOS (64KB)

oocoooo

oooooOO

Resewed for ROM on I/O cards

VGA BIOS ROM (Shadow, 32KB)

VGA Color Text

VGA Mono Text

VGA Graphics

Base memory

Jumper and DIP Switch Settings

Display Adapter and CPU Jumper Settings

Jumper

Setting

Function

A’

Enable the built-in VGA adapter

B

Disable the built-in VGA adapter so you can use a
d&play adapter on an option card as your primary
adapter

J4

A

Select DX2 CPU

B

select sx CPU

Factory setting

Factory set according to system CPU

External Cache Jumper Settings

Cache

size

OKB’

J7

32KB

A

A

A

A

A

A

B

A

B

A

128KB

B

B

A

A

A

l

Factory setting; change jumpers only if external cache

are installed

Hard Disk Drive Jumper Settings

Number

Single Drive

Drive

Slave

Drive

Conner

C/D

and DSP

no jumpers

Conner

no jumpers

Quantum

DS

DS

no jumpers’

l

CS (cable selection) is

the drive is a master if pin-28 is grounded

and a stave if pin-28 is not grounded.

DIP Switch Settings

Switch

1

Function
33 MHz CPU speed
25 MHz CPU

2

ON

25 MHz CPU speed

OFF

33 MHz

speed

3

ON

CPU present in PGA socket

OFF

CPU absent from PGA socket

4

ON’

Enable password

feature

O f f

password security feature

5

ON’

Select color monitor

OFF

Select monochrome monitor

Factory setting

l

* Factory set according to system type

Processor Chips

The 4SX/25 system can be upgraded with an Intel OverDrive

processor on the main system board to effectively double the

internal clock speed of the computer’s microprocessor.

Alternatively, the 4SX/25 accepts the Intel 487SX/25

microprocessor with built-m math coprocessor.

SIMM lnstallation

The computer comes with 4MB of memory on the main

system board. To increase the amount of memory in the

computer up to 36MB, install 36-bit, fast-page mode SIMMs

that operate at an access speed of 70ns or faster, with a

capacity of 1MB, 4MB, or 16MB.
The following table shows the possible SIMM configurations;

do not install memory in any other configuration.

SIMM Configurations

SIMM1

SIMM2

Total

0

4MB’

4MB

4MB

4MB

4MB

12MB

0

4MB

I

l

Standard memory on the system board

can occupy either socket

EPSON Equity 4+ 6
