8
GB
- Paper filter bag
- Switchable household nozzle
- Crevice nozzle
- 10 cross-head screws
- 2 plastic washers
Dispose of the packaging material in a
proper manner.
Assembly
Pull out the mains plug.
Danger of electric shock.
1. Plug the front steering castor (11) into
the slot on the front of the stainless
steel container (9). Fix the steering
castor with 2 crosshead screws.
2. Plug the attachment ports (15) with
the rear steering castor (14) into the
slot on the rear of the stainless steel
container (9). Screw these in place
with 2 crosshead screws.
3. Fit both wheels (12) and plastic wash-
ers (flat surface towards the equip-
ment). Fix each wheel with 1 cross-
head screw. Fit the hubcaps.
4. Fit the bow handle (1) onto the two
bow handle tie bars (2) and screw it in
place with 2 crosshead screws.
5. Fold down the bow handle (1) towards
the suction nozzle (8). Place the mo-
tor head (3) on the stainless steel
container (9). Close the stainless
steel container by folding up the bow
handle and fixing it with the locking
levers (the tension can be ad-
justed with the locking lever adjusting
screw). Several positions are possible
for the bow handle.
. Never.vacuum.without.a.filter!
6. Fit the power cable holder (4) onto the
motor head (3) and screw it in place
with 2 crosshead screws.
7. Fit the accessories:
- Connect the suction hose (21).
- Fit the handle (22)
- Fit the telescopic suction pipe (19).
(Press the knob on the telescopic
suction pipe in the direction and
separate to the desired length).
- Fit the desired nozzle (27/28).
To store the suction set during
breaks, push together the tel-
escopic suction hose and plug the
suction pipe holder into the socket
on the motor housing (see picture
below).
Switching on/off
Connect the mains plug.
Do not vacuum without a filter!
(How to insert the filter is described
in the chapters “dry vacuuming“
and “wet vacuuming“).
Switching.On:
On/Off Switch (see 6) In position “ I“
Switching.Off:
On/Off Switch (see 6) In position “ 0”
Dry vacuuming
1. For dry vacuuming, fit the pleated filter
(25) onto the filter basket on the motor
head (3). The sealing lip that curves
upward must point away from the mo-
tor head.
2. Fit the filter cover (24) and lock it with
a light turn:
Lock the filter cover
Unlock the filter cover
