EPSON Stylus Photo 700
3/98 EPSON Stylus Photo 700 - 5
Electrical
* This product is also designed for an IT power system phase-to-
phase voltage of 220
− 240 V.
** Check the label on the back of the printer for the voltage of your
printer.
Environmental
Temperature
Operation 50 to 95 °F (10 to 35 °C)
Storage * − 4 to 140 °F ( − 20 to 60 °C)
1 month at 104 °F (40 °C)
120 hours at 140 °F (60 °C)
Humidity (without condensation)
Operation 20 to 80% RH
Storage * 5 to 85% RH
*Stored in shipping container
Safety approvals
Safety standards UL 1950 with D3, CSA C22.2 No. 950
with D3
EMC FCC part 15 subpart B class B, CSA
C108.8 class B
Initialization
The printer can be initialized (returned to a fixed set of
conditions) in these ways:
Hardware initialization
When the printer is turned on, the printer mechanism is
initialized and the input data buffer and print buffer are
cleared. Printer settings are returned to their default values.
However, the printer mechanism is not initialized if the
printer is turned on within ten seconds after turning it off. In
this case, the printer caps the print head, and ejects any paper
in the paper path.
Software initialization
Software initialization clears the print buffer and returns
printer settings to their default values. However, it does not
initialize the printer mechanism or clear the data buffer.
Interface
Your printer is equipped with an 8-bit parallel interface and a
serial interface.
Parallel interface
The built-in parallel interface has the following characteristics:
Forward channel
Data format: 8-bit parallel, IEEE-1284
compatibility mode
Synchronization: STROBE pulse
Handshake timing: BUSY and ACKNLG signals
Signal level: TTL compatible
Connector: 57-30360 Amphenol connector or
equivalent
Reverse channel
Transmission mode: IEEE-1284 Nibble mode
Adaptable connector: 57-30360 Amphenol connector or
equivalent
Synchronization: Refer to the IEEE-1284
specification
Handshaking: Refer to the IEEE-1284
specification
Signal level: IEEE-1284 Level 1 device
Data transmission timing: Refer to the IEEE-1284
specification
Specification 120 V Model 220 − 240 V Model*
Input voltage
range** 99 to 132 V 198 to 264 V
Rated frequency
range 50 to 60 Hz
Input frequency
range 49.5 to 60.5 Hz
Rated current 0.4 A 0.2 A
Power
consumption Approx. 15 W (ISO/IEC 10561 Letter Pattern)
Approx. 5 W in standby mode (120 V model)
Approx. 5.5 W in standby mode (220
− 240 V
model)
Hardware
initialization ∗ The printer is turned on.
∗
The printer receives an INIT signal from the parallel
interface.
Software
initialization
∗
Software sends an ESC @ (initialize the printer)
command.
