Adjusting camera position – EverFocus EZ-PLATECAM2 User Manual
Page 7
5 . I n s t a l l a t i o n
• ADJUSTING CAMERA POSITION
7
* 1st Axis
90°
* 2nd Axis
360°
* 3rd Axis
360°
Loosen socket head allen screws to change angle
and/or rotate body about base.
WARNING !
To prevent injur y, this apparatus must be securely
attached to the mounting sur face with sufficient
strength to hold the weight of the camera including
w i n d a n d s n o w l o a d i n g i n a c c o r d a n c e w i t h t h e
installation instructions.
