4 . C o m p o n e n t a n d C o n t r o l N a m e s a n d F u n c t i o n s
6
① Sunshield
② Mounting Bracket
③ IR LED : 100ea
④ External Zoom and Focus adjustments
⑤ Camera Body
⑥ Body Lock Ring
⑦ Base Lock Ring
⑧ Cover to Access Menu Controls and LED Level Control
Pressing the “SETUP” button prompts the main setup menu.
“PUSH” button : To access the main setup menu
“U” Direction : Menu item UP selection
“D” Direction : Menu item DOWN selection
“L” Direction : To change data or decrease value
“R” Direction : To change data or increase value
LED Level : LED brightness – Adjusting brightness of the LED
(Factory default setting Level : Max)
①
② ②
③
④
⑤
⑥
⑦
⑧
