8 - ActionPC and ActionTower 8600 2/96
Connector Pin Assignments
* Active LOW logic
Parallel port connector pin assignments (J7)
Pin Signal Pin Signal Pin Signal
1 Strobe* 10 ACK * 19 Signal ground
2 Data 0 11 Busy 20 Signal ground
3 Data 1 12 PE 21 Signal ground
4 Data 2 13 Select 22 Signal ground
5 Data 3 14 AFD * 23 Signal ground
6 Data 4 15 Error * 24 Signal ground
7 Data 5 16 Init * 25 Signal ground
8 Data 6 17 Selectin * — —
9 Data 7 18 Signal ground — —
Serial port connector pin assignments (J5 and J6)
Pin Signal Pin Signal
1 Data carrier detect 6 Data set ready
2 Receive data 7 Request to send
3 Transmit data 8 Clear to send
4 Data terminal ready 9 Ring indicator
5 Ground — —
Mouse and keyboard connector pin assignments (J1 and J3)
Pin Signal Pin Signal
1 Data 4 VCC
2 NC 5 Clock
3 Ground 6 NC
VGA port connector pin assignments (J8)
Pin Signal Pin Signal Pin Signal
1 Red 6 Red ground 11 NC
2 Green 7 Green ground 12 Monitor detect
3 Blue 8 Blue ground 13 Horizontal sync
4 NC 9 NC 14 Vertical sync
5 Ground 10 Ground 15 NC
LED connector pin assignments (J21)
Pin Signal Pin Signal
1 NC 11 Power LED (yellow)
2 Turbo LED (yellow) 12 NC
3 Turbo LED (white) 13 Power LED (white)
4 NC 14 NC
5 NC 15 NC
6 NC 16 NC
7 NC 17 Speaker (red)
8 NC 18 NC
9 Hardware reset (white) 19 NC
10 Hardware reset (yellow) 20 Speaker (black)
* All odd-numbered pins are grounds
*Active low logic
HDD LED connector pin assignments (J22)
Pin Signal Pin Signal
1 Red 2 White
Power supply connector pin assignments (PS1)
Pin Signal Pin Signal
1 Power good 7 Ground
2 +5 VDC 8 Ground
3 +12 VDC 9 -5 VDC
4 -12 VDC 10 +5 VDC
5 Ground 11 +5 VDC
6 Ground 12 +5 VDC
Diskette drive connector pin assignments (J13)
Pin* Signal Pin* Signal
2 NC 20 Step
4 NC 22 Write data
6 NC 24 Write enable
8 Index 26 Track 0
10 Motor A 28 Write protect
12 Drive B 30 Read data
14 Drive A 32 Select header 0
16 Motor B 34 Disk change
18 Direction
IDE drive connector pin assignments (J14 and J15)
Pin Signal Pin Signal Pin Signal
1 RESET* 15 D1 29 NC
2 Ground 16 D14 30 Ground
3 D7 17 D0 31 IRQ14
4 D8 18 D15 32 IOCS16*
5 D6 19 Ground 33 A1
6 D9 20 NC 34 NC
7 D5 21 NC 35 A0
8 D10 22 Ground 36 A2
9 D4 23 IOW* 37 CS0*
10 D11 24 Ground 38 CS1*
11 D3 25 IOR* 39 Active*
12 D12 26 Ground 40 Ground
13 D2 27 IOCHRDY*
14 D13 28 BALE
