EdgeStar AP14000W - Manual (Page 17)

EdgeStar Portable Air Conditioner 14
Remote Control LCD Indicators
Indicators
Transmitter
Appears when the remote control is signaling
the unit.
Fan Speed
Shows the set fan speed.
Low, Medium, and High indicator will
appear depending on the mode you set.
Mode
Shows the set mode.
The Cool, Dehumidify, Heat (HS
model), or Fan indicator will appear
depending on the mode you set.
Set Temperature Shows the set temperature.
Fahrenheit and
Celsius Shows if the set temperature is in Fahrenheit
or Celsius.
Timer
Appears if the On Timer or Off Timer is
enabled.
Timed Hours
Shows the number of timed hours when the
Timer is enabled.
Mode Indicator
Function
Cooling The unit will cool and dehumidify.
Dehumidify The unit will remove moisture from the air.
Heat (HS model) The unit will run as a heat pump. (HS model)
Fan Only The unit will run as a fan and circulate air.
Fahrenheit and Celsius
Indicator
Timer Indicator
Timed Hours
Speed Indicator
Mode Indicators
Transmitter Indicator
Set Temperature
Indicator NOTE: If you used the control
panel to set up the unit, the
remote control will not
automatically update the
information shown on the
remote control’s LCD.
