LBI-39175A
14
SERVICEABLE PARTS
Control Unit - Switch Circuit CDF-368B/M
No serviceable parts.
Control Unit - Panel Control CMC-638
No serviceable parts.
Remote Control Unit - RIA NQZ-4882
J2 Connector, 18 Pin B19/5JBAX00020
Radio Unit - System Control CMC-682
F601 Fuse, 5 Amp B19/5ZFAP00008
IC604 AF Power Amplifier B19/5DAAA00350
J701 Connector, 18 Pin B19/5JDAG00315
Radio Unit - IF CMF-135
No serviceable parts.
Radio Unit - Synthesizer/Receiver/Exciter
CMN-352
No serviceable parts.
Radio Unit - Power Amplifier 110 Watts
CAH-515H
C25 Capacitor, 270 pF (136-153 MHz) B19/5CAAA05042
C25 Capacitor, 220 pF (150-174 MHz) B19/5CAAA03175
C26 Capacitor, 270 pF (136-153 MHz) B19/5CAAA05042
C26 Capacitor, 200 pF (150-174 MHz) B19/5CAAA05122
C27 Capacitor, 200 pF (150-174 MHz) B19/5CAAA05122
C28 Capacitor, 220 pF (150-174 MHz) B19/5CAAA03175
C33 Capacitor, Mica, 47 pF B19/5CMAB01252
C33 Capacitor, Mica, 47 pF B19/5CMAB01252
HC1 Power Module (136-153 MHz) B19/5DHAA00049
HC1 Power Module (150-174 MHz) B19/5DHAA00050
TR2 Transistor, NPN B19/5TCAF00510
TR3 Transistor, NPN B19/5TCAF00510
Radio Unit - Power Amplifier 55 Watts CAH-515L
C8 Capacitor, 270 pF (136-153 MHz) B19/5CAAA05042
C8 Capacitor, 220 pF (150-174 MHz) B19/5CAAA03175
C9 Capacitor, 270 pF (136-153 MHz) B19/5CAAA05042
C9 Capacitor, 220 pF (150-174 MHz) B19/5CAAA03175
C159 Capacitor, Mica, 47 pF B19/5CMAB01252
HC1 Power Module, (136-153 MHz) B19/5DHAA00051
HC1 Power Module, (150-174 MHz) B19/5DHAA00052
TR1 Transistor, NPN B19/5TCAF00510
Radio Unit - Power Amplifier 25 Watts CAH-515E
HC1 Power Module, (136-153 MHz) B19/5DHAA00049
HC1 Power Module, (150-174 MHz) B19/5DHAA00050
