OPERATING INSTRUCTIONS

Carpet Height Selector

This upright vacuum can be used on

multiple types of carpeting, bare floors

or upholstery with attachments.

To select a pile height setting:

1. Turn vacuum cleaner "Off".

2. Select a pile height setting by

sliding the carpet height selector

to the desired setting. (Fig. 4)

Removing & Emptying Dust Cup

HIGH:

shag carpet, long pile,

plush scatter rugs, tools

MED:

medium to long pile

LOW:

short to medium pile,

bare floors

FLOOR: very low pile, bare

floors

Suggested Pile Height Setting:

You may need to raise the height of the

vacuum to make some jobs easier,

such as scatter rugs and longer pile

carpets. Suggested settings are:

Warning: To reduce the risk of electric

shock, the power cord must be

disconnected before removing the dust

cup, dust cup filter,changing the filters or

performing maintenance/trouble shooting

checks.
The “Dust Cup” must always be emptied

when the dirt level reaches the "FULL"

line on the dust cup. To remove the dust

cup from the vacuum:
1. Press down on the dust cup

release button that is located on

the handle of the dust cup.

(Fig. 6)

2. Holding the dust cup from the

handle, pull the dust cup out

from the vacuum. (Fig. 7)

3. To empty the dust cup, hold it by

the handle over a garbage can

and press on the trap door

release button to empty. (Fig. 8)

Fig. 4

Fig. 6

Fig. 7

Fig. 8

Place unit in "HIGH" setting when using

attachments to prevent possible floor

damage. Always set the Carpet to Floor

selector to “Floor” setting when using

the accessories. (Fig. 5)
Attention: Special care is required

when vacuuming certain types of carpet

or floor covering. Always check the

carpet or floor covering manufacturer's

recommended cleaning instructions

before vacuuming.

Trap Door

Release

Fig. 5

Cleaning the HEPA Filter Frame

1. Before replacing the HEPA filter in the

HEPA Filter frame, you can (should)

rinse the frame in lukewarm water by

just running it under the tap to remove

any dust that is adhering to the frame.

(Fig. 13) Do NOT place in dishwasher.

Fig. 13

2. Make sure that the filter frame is

completely dry before replacing into

the dust cup. Always air dry for 24

hours.

Fig. 9

Fig. 12

1. To remove the HEPA

filter, remove the dust cup from the

unit.

2. To remove the dust cup

cover, hold the cover by

the handle, turn counter

clockwise and lift the

cover off. (Fig. 9)

3. Remove the HEPA

Rinseable "Tap Clean"

filter from the dust cup.

(Fig. 10)

4. Vigorously "TapClean"

the HEPA dust cup

filter on a hard

surface until no

more dust is

observed falling

out. (Fig. 11)

The HEPA filter may

also be washed by

running it under the

tap allowing the water

to run on the dirty side.

(Fig. 12) We

recommend washing

it once a month

or when suction appears

reduced. Always allow 24

hours for air drying before

replacing into the vacuum.

Fig. 10

Cleaning the Secondary Filter

1. Underneath the HEPA

filter there is a

secondary filter.

This is washable in

lukewarm water.

(Fig. 14) We

recommend washing

it when you are

washing your HEPA filter.

Always allow the secondary

filter to air dry for 24 hours

before replacing into the

vacuum. Never run

the vacuum without

the secondary filter in place.

Fig. 14

Please Note: The white material in the

HEPA filter will discolor over time - This is

NORMAL and will NOT affect the

performance of the filter.

IMPORTANT, Please Note : The Rinseable

“TapClean” HEPA Dust Cup Filter will stop

most of the tiniest dust particles and

airborne allergens from re-entering the air

you breathe. In fact, it stops 99.97% of all

particles as small as 0.3 microns - many

times smaller than a human hair!!! Because

of this incredible filtration performance, the

HEPA Dust Cup Filter will quickly

accumulate many fine dust particles inside

the white filter folds that are difficult to see

but which will eventually block or reduce

your suction power - if not cleaned properly.

Clean the HEPA Filter after each use as

described in this section.

Cleaning the HEPA Dust Cup Filter

Warning: Always empty the dust cup

and clean the HEPA dust cup filter

before each use and during prolonged

usage. Never over fill the dust cup -

remove dirt and clean the HEPA dust

cup filter each time the dust cup is

emptied during prolonged usage or risk

motor damage.

Fig. 11
