Electrolux Blast Chillers
Blast Chillers - 10/15 kg
Internet: http://www.electrolux.com/foodservice
HDAA010
2012-07-26
Subject to change without notice
RILSAN COATED GRID 881061 881061 881061
PRINTER HACCP BASIC VERS-REF.ELECR.CONTR 881532 881532 881532
PLASTIC COATED GRID-600X400 MM 880864 880864 880864
PAIR OF 1/1 GN AISI 304 S/S GRIDS 921101 921101 921101
KIT HACCP ADVANCED CONNECT. BC/BCF LW+CW 880183 880183 880183
COOK&CHILL KIT-6 GN OVEN/15KG BL.CHILLER 881528 881528
4 WHEELS FOR BLAST CHILLERS 881097
4 FEET FOR UNDERCOUNTER BLAST CHILLER 881493
3-POINT-SENSOR PROBE-BL.C/FREEZERS LW 880212 880212 880212
1 SINGLE-SENSOR PROBE-BL.C/FREEZERS LW 880213 880213 880213
ACCESSORIES
1 SINGLE-SENSOR PROBE-BL.C/FREEZERS LW 1 1
INCLUDED ACCESSORIES
Net weight - kg. 88 95 85
installed-electric 0.496 0.854 0.12
Power - kW
at evaporation temperature - °C -5 -5 7.2
Refrigerant power
Refrigeration power - W 550 707 1350
Refrigerant quantity - g. 660 800
Refrigerant type R134a R134a R134a
N° defrost in 24 hrs. 6 6 6
Compressor power - HP 1/4 3/8
Max load capacity - trays h 65 mm - n° 3 3 3
Trays type GN 1/1; 600x400 GN 1/1; 600x400 GN 1/1; 600x400
Door hinges Right Side Right Side Right Side
N° and type of door 1 1 1
height 850 970 975
depth/with open doors 700, 1407 760, 1500 770, 1450
width 762 760 760
External dimensions - mm
Cooling unit Built-In Built-In Remote
Gross capacity (D.I.N. 8952) - l. 72 115 115
UK Guide lines - chilling / freezing 10 15.2 15.2
NF Regulations - chilling / freezing 7.2 10.8 10.8
Productivity per cycle - kg.
Type A - 10 KG CHILLER B - 15 KG CHILLER B - 15 KG CHILLER
TECHNICAL DATA
RBC051
726658
RBC061
726620
RBC061R
726621
CONSTRUCTION
• Internal and external finishing in 304
AISI stainless steel and backpanel in
galvanized steel.
• High density polyurethane
insulation, 60 mm tickness, HCFC
free.
• Environmentally friendly: R134a as
refrigerant fluid.
•
Developed and produced in ISO
9001 and ISO 14001 certified factory.
• Inner cell with fully rounded corners.
• Door equipped with removable
magnetic gasket with hygienic design.
• Motors and fan waterproof
protected IP21.
• Evaporator with antirust protection.
• Ventilator (fan) swinging hinged
panel for access to the evaporator for
cleaning.
• Automatic heated door frame.
• Thermostatic expansion valve to
optimize the cooling unit efficiency.
• Adjustable feet 150 mm high
(except for code 726658).
• Stand alone printer as accessory.
• PC connection on request, gate RS
485.
INSTALLATION
• No water connections required.
• Waste water can be plumbed into
drain, but can also be collected in an
optional waste container.
*NF HYGIENE ALIMENTAIRE
certifying authority : AFAQ AFNOR
CERTIFICATION. Adress:11, Avenue
Francis de Pressense - 93571
Saint-Denis La Plaine Cedex - France.
Conformity with regulation NF031.
Certified guarantees: fitness for
cleaning, thermal performance.
