Warning – Exmark NAV20KC User Manual

Page 16

HOT

SURFACE

65-2690

WARNING

PART NO. 79-0360
LOCATION: On Front of Blower

Discharge Chute

PART NO. 98-5954
LOCATION: - On Gear Box Cover, Under Rubber Cover

- On Top of Deck, Under Gear Box Cover

- On LH Frame, Under PTO Shield

- On RH Lower Frame, behind fuel tank

PART NO. 103-8451
LOCATION: On RH Console

PART NO. 103-8812
LOCATION: On RH Console

PART NO. 65-2690
LOCATION: - On Frame LH side in Front

of Exhaust Cutout

- On Frame RH side behind

Exhaust Cutout

PART NO. 1-513747
LOCATION: On Battery Cover

PART NO. 103-8495
LOCATION: On Top of Mainframe, Under Hopper

PART NO. 103-8425
LOCATION: - On front console,

Under Seat

driveshaft

PART NO. 103-8444
LOCATION: On Hopper Door Hinge, Each Side

PART NO. 103-9034
LOCATION: On Rear of LH Drive

Wheel Fender
