ECS UPPER HANDLES and CONTROLS
13
Item Part No. Description Qty.
1 1-303020 Grip........................................................ 1
2 1-414234 Asm, Lever (1-412295-03) W/Grip.......... 1
3 3256-4 Washer, 3/8 Std ..................................... 2
4 323-11 Screw, HH 3/8-16 x 2-1/4 ....................... 1
5 322-9 Screw, HH 5/16-18 x 1 3/4 ..................... 2
6 3296-39 Nut, Nyloc 3/8-16 ................................... 1
7 1-806003 Hairpin, Cotter........................................ 3
8 103-1149 Link, Blade Engagement ........................ 1
9 1-413279 Turnbuckle ............................................. 1
10 3217-7 Nut, Hex 3/8-16...................................... 1
11 103-1566-03 Wld, OPC Lever LH................................ 1
12 ∇ 1-803322 Setscrew, 5/16-24 x 5/16........................ 2
13 1-303365 Bushing, Nylon....................................... 2
14 103-0769-03 Wld, OPC Lever Axle ............................. 1
15 1-303363 Spring, Opc Extension ........................... 1
16 103-1567-03 Wld, OPC Lever RH ............................... 1
17 1-807513 Bolt, Carriage #10-24 x 1/2 .................... 2
18
∇ 103-2605
Fitting, Fuel Bulkhead W/Strainer........... 1
19 109-3958 Cable, Throttle ....................................... 1
20 3296-2 Nut, Nyloc #10-24 .................................. 2
21 103-0770-03 Wld, ECS Upper Handle......................... 1
22 103-0815 Grip, Handle Bar .................................... 2
23 1-413152 Bearing .................................................. 4
24 103-2466-03 Lever, Drive LH ...................................... 1
25 103-0027 Bushing, Drive Lever.............................. 2
26 321-14 Screw, HH 1/4-20 x 2 3/4 ....................... 2
27 32128-33 Nut, Whizlock 1/4-20 .............................. 12
* 32128-33 Nut, Whizlock 1/4-20 .............................. 14
28 103-0464 Pin, Spring 1/8 x 1/2............................... 2
29 3256-22 Washer 1/4 SAE .................................... 10
30 1-303435 Washer, Spring Disc 1/4......................... 6
31 103-1371 Asm, Thumb Latch RH (Shown)............. 1
103-1372 Asm, Thumb Latch LH (Not Shown) ....... 1
32 ∇ 103-0235 Screw, HH 1/4-20 x 1-1/8 W/Nylon......... 2
33 103-2465-03 Lever, Drive RH ..................................... 1
34 3290-357 Nut, Whizlock 3/8-16 .............................. 4
35 98-5975 Washer, Spring Disc 3/8......................... 4
36 323-6 Screw, HH 3/8-16 x 1 ............................. 4
Item Part No. Description Qty.
37 3220-3 Nut, Jam 3/8-24 ..................................... 4
38 322-10 Screw, 5/16-18 x 2................................. 2
39 1-603716 Washer, Friction Disc............................. 1
40 1-323244 Washer, Friction..................................... 2
41 109-4650 Asm, Console ( 109-4649-03 )W/ Decals .. 1
* 109-4651 Asm, Console ( 109-4649-03 )W/ Decals .. 1
42 103-0773 Wld, Speed Shift .................................... 1
43 103-0423 Knob Nyloc 3/8-16 ................................. 1
44 3296-29 Nut, Nyloc 5/16-18 ................................. 4
45 1-323245 Spring, Compression ............................. 2
46 3256-23 Washer 5/16 SAE .................................. 5
47 321-3 Screw, HH 1/4-20 x 5/8.......................... 10
* 321-3 Screw, HH 1/4-20 x 5/8.......................... 12
48 1-413225 Rod, Speed Control ............................... 1
49 3220-2 Nut, Jam 5/16-24 ................................... 1
50 1-303105 Yoke ...................................................... 1
51 1-808280 Pin, Clevis 5/16 x 1 ................................ 1
52 109-0346 Cap, Fuel............................................... 1
53 103-2893 Asm, Fuel Tank W/Fitting....................... 1
54 1-633023 Stud, Fuel Tank ..................................... 2
55 1-633349 Spring, Fuel Tank .................................. 2
56 1-805005 Washer, Lock 5/16 Heavy ...................... 2
57 322-3 Screw, HH 5/16-18 x 3/4........................ 2
58 103-1796 Cable, Choke......................................... 1
59 103-1797-01 Bracket, Choke Cable ............................ 1
60 1-303077 Clamp, Fuel Line.................................... 4
61 109-0306 Hose, Fuel Line 6” ................................. 1
62 1-603770 Valve, Fuel............................................. 1
63 109-0293 Hose, Fuel Line 8.5”............................... 1
64 Kawasaki PN 41019-1055 Filter W/6” Fuel Line ..... 1
65 3296-47 Nut, Nyloc 5/16-18 Thin ......................... 2
66 1-303287 Tie, Cable 5 1/2 ..................................... 1
67 103-2513 Asm, Drive Lever RH ............................. 1
103-2514 Asm, Drive Lever LH.............................. 1
68 103-2463 Balljoint.................................................. 2
69 103-0503 Bracket, Shifter Slide ............................. 1
70 103-0489-03 Bracket, Opc Axle .................................. 1
71 3219-3 Nut, Hex 3/8-24...................................... 2
Exmark red touch up paint (spray paint - P/N 1-850337 - .6 oz liquid bottle - P/N 103-9140).
∇ Use Pro-Lock nut type, Part no. 1-840022 (.5cc tube) on setscrew threads, on thumblatch screws and on fuel fitting.
Use Pro-Lock retaining type, Part no. 1-840023 (.5cc tube) on inside of bore of OPC hub and on fuel tank studs,
where studs are inserted into tank.
* Manual start only.
Electric start only.
