Exmark 000 & Higher - Manual (Page 10)

ENGINE DECK GROUP
9
Item Part No. Description Qty.
1* 323-11 Screw, HH 3/8-16 x 2-1/4 ....................... 2
323-11 Screw, HH 3/8-16 x 2-1/4 ....................... 1
2* 98-5975 Washer, Spring Disc 3/8......................... 11
98-5975 Washer, Spring Disc 3/8......................... 13
3 103-3506 Seal, Single Lip ...................................... 1
4 1-513034 Bearing, Pivot......................................... 2
5 302-19 Zerk, 1/4-28 Str ...................................... 1
6 1-414143 Asm, Bellcrank (1-412285-03) W/Brgs 1
7 322-6 Screw, HH 5/16-18 x 1-1/4 ..................... 1
8 321-6 Screw, HH 1/4-20 x 1 ............................. 2
9 32128-33 Nut, Whizlock 1/4-20 .............................. 4
10 1-523498 Spring, Motion Control ........................... 1
11 103-7398 Spring, Belt Tension............................... 1
12 1-543007 Spacer ................................................... 1
13 1-213069 Washer .................................................. 1
14 3296-29 Nut, Nyloc 5/16-18 ................................. 3
15 3256-4 Washer, 3/8 Std ..................................... 2
16 3290-357 Nut, Whizlock 3/8-16 .............................. 19
17 1-413282 Linkage .................................................. 1
18 1-806003 Hairpin, Cotter........................................ 1
19 109-1297 Asm, Deck (103-7345-01) W/Decals ...... 1
20 323-4 Screw, HH 3/8-16 x 3/4 .......................... 2
21 1-633068 Arm ........................................................ 1
22 32128-20 Nut, Whizlock 5/16-18 ............................ 15
23 1-303334 Washer, Spring Disc 5/16....................... 5
24* 1-322110 Wld, Belt Guide ...................................... 1
25* 322-7 Screw, HH 5/16-18 x 1-1/2 ..................... 3
322-7 Screw, HH 5/16-18 x 1-1/2 ..................... 4
26* 322-9 Screw, HH 5/16-18x 1-3/4 ...................... 1
27 3256-3 Washer, 5/16 Std ................................... 2
28* 1-323366 Ring, Split .............................................. 1
29 3296-39 Nut, Nyloc 3/8-16 ................................... 5
30* 323-6 Screw, HH 3/8-16 x 1 ............................. 8
323-6 Screw, HH 3/8-16 x 1 ............................. 10
31 1-412080-01 Mount, Wheel Motor (36”) ...................... 2
1-412082-01 Mount, Wheel Motor (48”& 52”) .............. 2
32 323-6 Screw, HH 3/8-16 x 1 ............................. 8
33 1-602997 Hub, W/Studs......................................... 2
1-633926 Stud, Wheel 1/2-20 ................................ 8
34 1-413473 Asm, Wheel & Tire (36”)......................... 2
1-413474 Tire 16 x 6.50-8 (36”) ............................. 2
1-613263 Asm, Wheel & Tire (48” & 52”) ............... 2
1-613264 Tire 16 x 7.50-8 (48” & 52”) .................... 2
1-603715 Wheel .................................................... 2
35 242-50 Nut, Lug 1/2-20 ...................................... 8
36 32136-5 Nut, Slotted 3/4-16 ................................. 2
37 1-806800 Pin, Cotter 9/64 x 1-1/2 .......................... 2
38 1-807264 Key, 1/4 x 1/4 x 2-5/8 ............................. 1
39 103-6309 Asm, Drive Sheave ................................ 1
40 1-603609 Bushing.................................................. 1
41 1-373034 Washer .................................................. 2
42 1-603610 Washer, Spring Disk 7/16....................... 2
43
∇ 3212-10
Screw, HH 7/16-20 x 2-1/2 ..................... 1
44 3256-24 Washer, 3/8 SAE ................................... 2
Item Part No. Description Qty.
45 109-4077 Pulley, Idler............................................ 1
46 1-603496 Bushing, Idler......................................... 1
47 103-8599 Spring, Extension................................... 1
48 109-1296 Kit, Idler Arm (109-1208-03) W/Brgs ...... 1
49 1481 Zerk, 45° 1/4-28 ..................................... 2
50 98-5961 Screw, HH 3/8-16 x 4 Gr8 ...................... 1
51 323-9 Screw, HH 3/8-16 x 1-3/4....................... 2
52* 1-809069 Screw, HSH #10-24 x 7/8....................... 1
53* 1-323365 Chain, Cold Start ................................... 1
54* 3256-14 Washer, #10 Std .................................... 1
55* 3296-2 Nut, Nyloc #10-24 .................................. 1
56 1-807272 Key, 5mm x 5mm x 25mm ..................... 2
57
∇ 1-803050
Setscrew, 5/16-18 x 3/4 ......................... 4
58 109-1057 Belt, Pump Drive.................................... 1
59 1-413010 Sheave, Pump Drive .............................. 2
60 103-6317 Belt, Blade Clutch .................................. 1
61 1-807259 Key, 1/4 x 1/4 x 1 ................................... 1
62 103-6308 Sheave W/Shaft..................................... 1
63 1-413111 Bearing, Clutch ...................................... 2
64 32120-8 Ring, Retaining ...................................... 2
65 1-413012 Spacer, Bearing ..................................... 1
66 1-523157 Washer, Spacer ..................................... 1
67 1-413049-01 Plate, Clutch Pivot ................................. 1
68 322-5 Screw, HH 5/16-18 x 1........................... 6
69 1-413207 Pivot, Bearing ........................................ 2
70 1-414418 Asm, Clutch Arm (1-412417-03)
W/Bearings ............................................ 1
71 1-413235 Washer, Spacer ..................................... 1
72 1-412138-03 Wld, Pivot Pin ........................................ 1
73 322-3 Screw, HH 5/16-18 x 3/4........................ 3
74 1-413062 Band, Brake........................................... 1
75 323-8 Screw, HH 3/8-16 x 1 1/2....................... 2
76 103-6310 Wld, Belt Guide...................................... 1
77 1-412031 Sheave W/Drum (36” & 52”)................... 1
1-412028 Sheave W/Drum (48”) ............................ 1
78 ∇ 1-800521 Screw, HH 3/8-24 x 1............................. 1
79 1-413009-01 Plate, Guard .......................................... 1
80 103-2056 Shield, Trailing....................................... 1
81 1-413510 Clip, Loom 1/2 ....................................... 2
82 1-413511 Hanger, Drag Shield .............................. 2
83 103-3442 Battery, Cover (1-543891) W/Decal ....... 1
84 1-543792 Wingnut, Nyloc 1/4-20............................ 2
85 1-413541 Trim-Lok, 1/8 x 5.................................... 1
86 103-1098 Stand W/ Trim-Lok................................. 1
87 1-543882 Bolt, Hold Down ..................................... 2
88 323-7 Screw, HH 3/8-16 x 1 1/4....................... 1
89 32120-10 Ring, Retaining ...................................... 2
90 1-807019 Key, Woodruff 1 x 1/4 ............................ 2
91 103-3504 Bearing, Spherical ................................. 2
92 106-7159 O-Ring ................................................... 2
93 103-5677 Spacer ................................................... 1
94 103-3505 Seal, Double, Lip ................................... 1
95 103-2916 Guard, Top ............................................ 1
96 95-5975 Washer, Spring Disc .............................. 8
Exmark red touch up paint (spray paint - P/N 1-850337 - .6 oz liquid bottle - P/N 103-9140).
*
Manual start only.
Electric start only.
∇ Use Pro-Lock (nut type, Part no. 1-840022, 5 ml tube):
ƒ on setscrew threads.
ƒ on sheave retaining bolt in engine crankshaft.
ƒ on sheave retaining bolt on clutch arm.
Apply antiseize:
ƒ between engine crankshaft and pump and blade drive sheave.
ƒ between sheave w/shaft and bearing bores and sheave w/drum.
ƒ between pump shafts and sheaves.
