Echo QV-670 User Manual
Page 19
REMARKS
DESCRIPTION
QTY
PART NUMBER
ITEM
COVER, ENGINE
1
A160000210
1
SCREW 5X20
5
90016205020
2
LABEL, CAUTION
1
89019132632
3
DEFLECTOR, HEAT
1
V341000010
4
CYLINDER
1
A130000171
5
BELLOWS, INTAKE
1
A202000010
6
SCREW 5X14
2
90016205014
7
SCREW 5X25
4
90016205025
8
GASKET, CYLINDER.
1
10101032431
9
INCLUDES ITEMS 11-14
PISTON KIT
1
P021002790
10
RING, PISTON
2
10001132430
11
PIN, PISTON
1
V610000000
12
CIRCLIP
2
V580000000
13
BEARING, NEEDLE
1
10001232430
14
CRANKSHAFT ASY
1
A011000130
15
WOODRUFF KEY
1
10014230830
16
INCLUDES ITEMS 18-27
CRANKCASE KIT
1
10020438133
17
OIL SEAL
1
10021219830
18
BEARING, BALL
2
90081036202
19
GASKET, CRANKCASE
1
10024232430
20
STUD, GUIDE BAR
2
43301119830
21
DOWEL PIN
2
10021502830
22
SPRING PIN 5X10
1
90034550010
23
OIL SEAL
1
10021232430
24
VALVE, CHECK
1
43611413930
25
PLATE, EYE
1
V150000570
26
SCREW
1
90024204008
27
SCREW 5X20
2
90016205020
28
SCREW 5X35
4
90016205035
29
SCREW 5X14
1
90023805014
30
CUSHION 5
1
10091732430
31
INCLUDES ITEMS 33-36
CAP ASY
1
43600139231
32
CONNECTOR, CAP
1
A365000050
33
SCREW 3X8
1
90024603008
34
LINK, RETAINER
1
13105019830
35
O-RING
1
90072502025
36
CUSHION
2
V420000530
37
COLLAR 5
2
V353000110
38
SCREW 5X25
2
90010505025
39
CAP, CUSHION
2
10091819830
40
SPRING
1
V450000150
41
PLATE, EYE
1
V150000750
42
SCREW 4X8
1
90016204008
43
BOLT 5
1
V203000050
44
SCREW 5X14
1
90016205014
45
99922203483 _03
- 19 -
REVISED 10/02/08
QV-670 Quik Vent Saw
Engine, Cylinder Cover
