Echo QV-670 User Manual
Page 15
REMARKS
DESCRIPTION
QTY
PART NUMBER
ITEM
SCREW 4X12
3
90016204012
1
COVER, OIL PUMP
1
43760537630
2
WASHER 12
1
V309000010
3
GEAR, WORM
1
43706319930
4
AUTO-OILER ASY
1
43700237530
5
O-RING 3
2
90072000003
6
PIPE, OIL
1
43721132430
7
CONNECTOR, PIPE
1
43721232430
8
CLIP
1
13201326630
9
GROMMET
1
13211512330
10
PIPE, OIL
1
43721038330
11
FILTER, OIL
1
43620514730
12
REPOWER BULK OPTION: 90015
PIPE, OIL - 3X6X200mm
1
43721015130
13
INCLUDES ITEMS 15-24
OIL PUMP ASY
1
43710038831
14
NIPPLE
1
43711819830
15
O-RING
2
43712203430
16
VALVE, BALL
2
43701200330
17
SPRING, VALVE
2
V450000290
18
PISTON, OIL PUMP
1
43711238731
19
O-RING 7
1
90072000007
20
SPRING
1
43711119830
21
BODY, OIL PUMP
1
43711019831
22
PIN, SPRING - 2X16
1
90034520016
23
ADAPTER, OIL PUMP
1
43712110130
24
CONNECTOR, PIPE
1
43721232630
25
REPOWER BULK OPTION: 90017
PIPE, OIL - 3X6X125
1
43721632630
26
CONNECTOR, PIPE
1
43723232630
27
BRACKET, OIL PUMP
1
43741319830
28
SCREW 4X10
1
90025204010
29
WASHER 5
1
90060300005
30
SCREW 5X20
1
90025205020
31
KNOB
1
43703937630
32
SPRING
1
43701519830
33
E-RING 3
1
90070000003
34
99922203483 _03
- 15 -
REVISED 10/02/08
QV-670 Quik Vent Saw
Auto-Oiler
