Turbo iDDR Rack-Mount Instructions
3
Mounting the Rack Slides
Mounting the Rack Slides
Choose the proper set of rail mounting holes on the rack. Notice that the hole spacing
can vary with the rack type. When mounting the slides in racks with EIA spacing,
make sure that the slides are attached to the 0.5-inch spaced holes.
Front and rear rack rail mounting hardware is provided with the rack mount kit.
Mount the rails using the enclosed hardware. Make sure the stationary sections are
horizontally aligned and are level, as well as parallel to each other.
1.250 in
MIL STD 189
“UNIVERSAL” SPACING
0.500 in
0.625 in
1.250 in
1.250 in
0.625 in
