Steering Remote Control
Importing steering remote data (U.S.A. only)
Steering Remote Control
The vehicle’s factory loaded steering remote becomes inoperable when the CD3200 is installed.
The ECLIPSE website (E-iSERV) provides software that enables steering remote operation even
with the installation of the main unit. Import this software into your CD3200.
How to operate the Steering Remote Control
Download the file for Steering Remote setting from the E-iSERV website, then write
it to USB memory or CD-R.
ATTENTION
• Data downloaded from the E-iSERV website should be saved to folders created in the USB
drive as shown below (NOTE: in order for the system to properly recognize and load steering
remote data, the user must create and name their folders as shown in the diagram below).
ECLIPSE
DATA
File extension
XXXXXXX.ssw Automatically generated filename
Must be created by user
• Files retrieved from the E-iSERV website are given automatically generated fi lenames upon download.
• The main unit cannot be in USB music playing mode during this procedure.
• The main unit can only import fi les located in the root directory of the CD-R.
File extension
XXXXXXX.ssw Automatically generated filename
• Disc formats that may be used are as follows:
• CD-ROM (MODE 1)
• CD-ROM (MODE2_FORM 1)
* CD-ROMs written in MODE2_FORM2 cannot be read.
• When data is imported from a CD-R, the importing process well take a long time if a lot
of data other than the import data has also been saved to the CD-R.
