LDK 4426 3G Camera Triax to 3G Fiber Converter User’s Guide (v2.0)
23
Chapter 2 - Operation
2.3.3 Base station power indicator
This green indicator lights when base station power is used to power the camera.
Indicators
Condition
Indicators
Condition
BS PWR green:
Base Station power is in
use.
BS PWR off:
Base Station power is in
not in use.
BS
PWR
BS
PWR
