Operation – Using the Control Panel
Turning the Unit On or Off
Press the Power button and the unit will start in auto mode. If the ambient temperature is:
o
F, the unit will operate in cooling mode.
- Higher than 68
o
F but below or equal to
o
F, the unit will operate in fan mode.
- Below 68
o
F, the unit will operate in heating mode.
An indicator light will display next to the corresponding mode.
*NOTE: The display window shows the ambient room temperature from 32
o
F to 122
o
F
To turn the unit off, press the Power button again.
Selecting Between Automatic, Cooling, Heating, or Fan Mode
Press the MODE button to select the desired mode: automatic, cooling, heating or fan.
The indicator of your selected mode comes on.
Control Panel Parts
FIG.12
1. Power button
2. Timer button
3. Timer operation indicator
4. Temperature up button
5. Compressor indicator
6. Water Full indicator
7. Temperature down button
8. Low fan speed indicator
9. High fan speed indicator
10. Heat mode indicator
11. Fan mode indicator
12. Cooling mode indicator
13. Automatic
mode indicator
14. Mode (function) option button
15. Fan speed button
16. Display
window
17. Receiver for remote control
- Higher than 74
74
1
TIMER
POWER
UP
DOWN
A/C Water
SPEED
MODE
17 16 15 14 13
11
12
10
9
8
7
6 5
4
3
2
AUTO
