K2 Edge User Manual - document version: 4.0 – Page 24
14 Supported input/output broadcast format
combinations
IO-ports can be configured as SDI-inputs. The incoming signal can be made available to one
or more Channels, for example for coverage of live events. Inputs behave much like clips on
the K2Edge; they can be queued and started at any time. Inputs be can shared over multiple
Channels, and each Channel can handle several inputs simultaneously.
In Channel Composer, the Live Object is used to manage inputs.
At the moment there is no support for auto sensing the incoming signal’s format. The input
broadcast format does not have to be an exact match of the Channel/output format, but both
frame rate and interlaced/progressive mode must match.
Supported Input/Output broadcast format combinations are:
• PAL -> 1080@50i
• 1080@50i -> PAL
• NTSC -> [email protected]
• [email protected] -> NTSC
